SonicWall 02-SSC-9586 NSa 6700 Essential Edition security appliance View larger

SonicWall 02-SSC-9586 NSa 6700 Essential Edition security appliance

New

"High-performance 36Gbps Next-Generation Firewall."

×




  • New

Detailed Specifications

SonicWall 02-SSC-9586 NSa 6700 36 Gbps Next-Generation Firewall

Overview

The SonicWall NSa 6700 is a high-performance, next-generation firewall (NGFW) designed to deliver robust security for medium to large-sized enterprises and distributed environments. This advanced security appliance, part of the Gen 7 NSa Series, addresses the critical need for multi-gigabit threat prevention and comprehensive network protection without compromising performance. It effectively safeguards against evolving cyber threats, including zero-day attacks and encrypted traffic, ensuring network integrity and business continuity for organizations with demanding security requirements. Leveraging SonicWall's innovative Reassembly-Free Deep Packet Inspection (RFDPI) and Real-Time Deep Memory Inspection (RTDMI) technologies, the NSa 6700 provides unparalleled threat detection capabilities. It inspects all traffic, including encrypted TLS/SSL and SSH sessions, at multi-gigabit speeds to identify and block advanced malware, intrusions, and application-layer threats. This deep-level inspection is critical for protecting sensitive data and intellectual property in today's sophisticated threat landscape, offering a strong defense against ransomware and other advanced persistent threats. Packaged in a 1U rack-mountable form factor, the NSa 6700 seamlessly integrates into existing IT infrastructures. Running on the intuitive SonicOS 7.0, it offers flexible deployment options, including secure SD-WAN capabilities for distributed networks and a built-in wireless controller to extend secure wireless access. Management is streamlined through a single pane of glass, facilitating easy policy configuration and enabling cloud-based monitoring and reporting for enhanced operational efficiency and simplified administration.

Key Features

  • High-speed multi-gigabit threat prevention throughput.
  • Advanced RFDPI and RTDMI for deep threat analysis.
  • Decrypts and inspects TLS/SSL and SSH traffic in real time.
  • High port density with 40GbE, 25GbE, and 10GbE interfaces.
  • Integrated Secure SD-WAN for optimized network routing.

Specifications

SpecificationValue
Brand SonicWall
Part Number 02-SSC-9586
Product Type Next-Generation Firewall
Series NSa 6700 Series
Firewall Throughput 36 Gbps
Threat Prevention Throughput 19 Gbps
Application Inspection Throughput 20 Gbps
IPS Throughput 20 Gbps
Anti-Malware Throughput 18.5 Gbps
DPI SSL Throughput 9 Gbps
Maximum Connections (SPI) 8,000,000
New Connections/Second 228,000/sec
Site-to-Site VPN Tunnels 6,000
VLAN Interfaces 512
Max Single Sign-On Users 70,000
Network Interfaces 2x40GbE, 8x25GbE, 4x10G SFP+, 4x10G Cu, 16x1GbE Cu
USB Ports 2 x USB 3.0
Console Port 1 x RJ-45
Management Port 1 x RJ-45
Form Factor 1U Rack-mountable
Operating System SonicOS 7.0
Dimensions (H x W x D) 1.8 x 16.9 x 18.1 inches
Weight 17.9 lbs
Max Power Consumption 139.2 W
Redundant Power Supply Yes
