Detailed Specifications
SonicWall TZ570 (03-SSC-3010) - Gen-7 5 Gbps Next-Generation Firewall Appliance
Overview
The SonicWall TZ570, SKU 03-SSC-3010, is a Gen-7 next-generation firewall designed for medium-to-large branch offices and distributed enterprises. It provides 5 Gbps firewall throughput and 1.5 Gbps threat prevention, ensuring high performance while inspecting network traffic for malware, intrusions, and applications.The appliance supports up to 250 site-to-site or remote VPN tunnels, making it suitable for secure multi-branch connectivity. Hardware features include 12×1 GbE RJ-45 ports, 2×SFP ports, and a console port for flexible network integration. Running SonicOS 7, the TZ570 supports SD-WAN, VLANs, zero-touch deployment, and centralized management.Expandable storage (up to ~512 GB) allows local logging, caching, and firmware backup. The TZ570's compact rack-mountable design enables easy deployment in office or data center environments while delivering enterprise-grade firewall protection.
Key Features
5 Gbps firewall throughput × high-performance inspection for branch traffic.
1.5 Gbps threat prevention × IPS, anti-malware, and deep packet inspection.
250 IPSec VPN tunnels × secure remote and site-to-site connections.
12×1 GbE + 2×SFP ports × flexible wired connectivity for LAN/WAN.
Expandable storage × up to ~512 GB for logs, caching, and backups.
SonicOS 7 × SD-WAN, zero-touch provisioning, VLAN segmentation, centralized management.
Technical Specifications
| Specification | Detail |
|---|
| Brand | SonicWall |
| Part Number | 03-SSC-3010 |
| Product Type | Next-Generation Firewall Appliance |
| Firewall Throughput | 5 Gbps |
| Threat Prevention Throughput | 1.5 Gbps |
| Application Inspection Throughput | 2.0 Gbps |
| IPS / IDS Throughput | 2.0 Gbps |
| Anti-Malware (DPI) Throughput | 1.5 Gbps |
| TLS/SSL (DPI-SSL) Throughput | 800 Mbps |
| IPSec VPN Throughput | 2.0 Gbps |
| New Connections / Second | 18,000 |
| SPI Connections (Max) | 1,500,000 |
| DPI Connections (Max) | 400,000 |
| DPI-SSL Connections (Max) | 50,000 |
| VLAN Interfaces | 256 |
| Interfaces / Ports | 12×1 GbE RJ-45, 2×SFP, 1×Console |
| Storage | Expandable up to 512 GB |
| Operating System | SonicOS 7.0 |
| Form Factor | 1U Rackmount |
| Power Consumption | ~25 W |
| Power Supply | External, 100-240 VAC |
| Operating Temperature | 0-40 °C |
