Detailed Specifications
SonicWall TZ570 (03-SSC-3019) - Gen-7 4 Gbps Next-Gen Firewall + 3-Year Essential
Overview
The SonicWall TZ570, SKU 03-SSC-3019, is a Gen-7, desktop/1U rack-mount next-generation firewall designed for modern branch and edge deployments. This particular SKU includes 3 years of Essential Protection Services plus 1 year of Cloud Secure Edge, giving you full security coverage × IPS, anti-malware, content filtering, real-time deep memory inspection, and centralized security policy management.It delivers 4 Gbps firewall throughput and 2 Gbps threat prevention throughput, handling high-speed traffic and intensive inspection tasks without becoming a bottleneck. The device supports 8 × 1 GbE RJ-45 ports and 2 × 5 GbE SFP+ ports, making it suitable for both local LAN and multi-gig uplinks.Powered by SonicOS 7, the TZ570 supports SD-WAN, zero-touch provisioning, and management via Network Security Manager or REST APIs. With a connection rate of 16,000 new sessions per second, and support for 200 site-to-site VPN tunnels, it's ideal for distributed offices needing strong performance and security.
Key Features
4 Gbps firewall throughput × sustains large-scale, high-speed traffic.
2 Gbps threat prevention × enables deep packet, IPS, and SSL inspection.
Multi-gig connectivity × 8×1 GbE + 2×5 GbE SFP+ for flexible deployment.
3-year Essential Protection + 1-year Cloud Secure Edge × full service and cloud-based management.
SonicOS 7 × enterprise-grade SD-WAN, zero-touch provisioning, centralized control.
High VPN capacity × supports up to 200 IPsec tunnels for remote sites.
Technical Specifications
| Specification | Detail |
|---|
| Brand | SonicWall |
| Part Number | 03-SSC-3019 |
| Product Type | Next-Generation Firewall Appliance + 3-Year Essential Bundle |
| Firewall Throughput | 4 Gbps |
| Threat Prevention Throughput | 2 Gbps |
| Management / OS | SonicOS 7.0 |
| Interfaces / Ports | 8×1 GbE RJ-45, 2×5 GbE SFP+, 2×USB 3.0, 1×Console |
| VPN Throughput (IPSec) | 1.8 Gbps |
| New Connections / Sec | 16,000 |
| Maximum SPI Connections | ~1,250,000 |
| Maximum DPI Connections | ~400,000 |
| TLS/SSL Inspection Throughput | 750 Mbps |
| VLAN Interfaces | 256 |
| Form Factor | Desktop / 1U Rack-mount |
| Power Consumption | 13.4 W (100-240 V) T |
| Storage / Expansion | Expandable up to 256 GB |
| SSL VPN / VPN Tunnels | 200 site-to-site, 500 max IPSec clients |
| Operating Temperature | 0-40 °C |
