SonicWall TZ670 (02-SSC-5685) - Gen-7 5 Gbps Next-Gen Firewall with 10 GbE
Overview
The SonicWall TZ670, SKU 02-SSC-5685, is a high-performance Gen-7 desktop/rackable next-generation firewall designed for mid-sized businesses and distributed enterprise (e.g., SD-Branch). It combines multi-gigabit connectivity with strong security, offering 8 × 1 GbE ports, 2 × 10 GbE SFP+ ports, plus 2 USB 3.0 and a console interface.This model offers up to 5.0 Gbps firewall throughput and 2.5 Gbps threat prevention, enabling real-time inspection of high-speed traffic, including encrypted sessions. With 2 expansion slots (SFP/SFP+), you can scale uplinks or fiber connectivity as needed. It also supports zero-touch provisioning and integrates with SonicWall's cloud management + SD-WAN capabilities through SonicOS 7.0.Its expandable storage (up to 256 GB) supports local logging, caching, and reporting. It's well-suited for remote offices, branch sites, or any deployment where high-speed WAN links and strong security are required, without using rack-heavy data-center hardware.
Key Features
5 Gbps firewall throughput × supports large Internet or WAN connectivity without bottlenecks.
2.5 Gbps threat prevention × protects against malware, IPS, and encrypted threats.
10-Gigabit connectivity × 2×10 GbE SFP+ ports + 8×1 GbE for high-speed links.
SonicOS 7.0 × SD-WAN ready, zero-touch deployment, and modern management.
Expandable storage up to 256 GB × for logging, reporting, and firmware backups.
2-year Advanced Protection × includes anti-virus, IPS, application control, and more.
Technical Specifications
| Specification | Detail |
|---|
| Brand | SonicWall |
| Part Number | 02-SSC-5685 |
| Product Type | Next-Generation Firewall Appliance + 2-Year Service Bundle |
| Firewall Throughput | ~5.0 Gbps |
| Threat Prevention Throughput | ~2.5 Gbps |
| Management / OS | SonicOS 7.0 |
| Interfaces / Ports | 8×1 GbE RJ-45, 2×10 GbE SFP+, 2×USB 3.0, 1×Console |
| Encryption / Authentication | DES, 3DES, MD5, SHA-1, AES 128/192/256 bit |
| Expansion Slots | 2 × SFP / SFP+ |
| VPN Throughput | ~2.1 Gbps (IPSec) |
| Concurrent Sessions | SPI: ~1,500,000 / DPI: ~500,000 |
| New Connections per Second | ~25,000 |
| VLAN Support | Up to 256 |
| Storage | 32 GB built-in, expandable to 256 GB |
| Power | External power adapter |
| Dimensions | ~225 mm × 150 mm × 35 mm |
| Weight | ~0.97 kg |
| Operating Temperature | 0-40 °C |
| Warranty / Service | 2-Year Secure Upgrade Plus - Advanced Edition |
