SonicWall NSa 2700 (02-SSC-7369) - Gen-7 5.2 Gbps Next-Gen Firewall
Overview
The SonicWall NSa 2700, part number 02-SSC-7369, is a rack-mount, seventh-generation next-generation firewall targeted at medium-to-large enterprise perimeters or data-center edges. This SKU comes bundled with a 1-year TotalSecure Essential license, giving you intrusion prevention, anti-malware, application control, URL/content filtering, sandboxing (Capture ATP), and 24×7 support.On the hardware side, it delivers ~5.2 Gbps firewall throughput (with all security services off) and 3.0 Gbps threat prevention throughput, making it capable of handling heavy inspection and encrypted traffic. It supports 16 × 1 GbE ports plus 3 × 10 Gb SFP+ for uplinks or aggregation.The NSa 2700 runs SonicOS 7.0, which enables SD-WAN, zero-touch provisioning, and centralized management. With high connection capacity (SPI + DPI) and strong VPN performance (2.1 Gbps IPsec), it's well-suited for distributed enterprises, large branches, or edge-firewall deployments.
Key Features
5.2 Gbps firewall throughput × capable of handling high-volume traffic at the perimeter.
3.0 Gbps threat prevention × provides deep inspection for malware, IPS, and app control.
High port density × 16×1 GbE + 3×10 GbE SFP+ for flexible network integration.
2.1 Gbps IPsec VPN × strong site-to-site or encrypted backbone connectivity.
Zero-touch deployment & SD-WAN × simplifies roll-out across distributed offices.
SonicOS 7.0 × modern UI, improved workflows, and unified security + networking.
Technical Specifications
| Specification | Detail |
|---|
| Brand | SonicWall |
| Part Number | 02-SSC-7369 |
| Product Type | Network Security / Firewall Appliance + Security License Bundle |
| Firewall Throughput | ~5.2 Gbps |
| Threat Prevention Throughput | 3.0 Gbps |
| Management | SonicOS 7.0 × Web UI, CLI, centralized NSM |
| Interfaces | 16×1 GbE RJ-45, 3×10 Gb SFP+, 2×USB 3.0, 1×Console, 1×Mgm |
| VPN Throughput (IPSec) | ~2.10 Gbps |
| Connections / Session Capacity | SPI: ~1,500,000; DPI: ~500,00 |
| Site-to-site VPN Tunnels | 250 tunnels |
| Operating Temperature | 0-40 °C |
| Storage | 64 GB M.2 SSD, expansion up to 256 GB |
| Warranty / Support | 1-Year TotalSecure Essential Edition included |
