Teltonika TRB142107000 4G LTE Industrial Router View larger

Teltonika TRB142107000 4G LTE Industrial Router

TRB142107000

New

Industrial 4G LTE Router
×




Detailed Specifications

Teltonika TRB142107000 4G LTE Industrial Router

Overview

The Teltonika TRB142107000 is an industrial 4G LTE Cat 4 cellular gateway engineered for engineers and integrators needing resilient WAN connectivity with flexible interfacing options. It combines 4G LTE with 3G/2G fallback, dual SIM automatic failover, and a rich mix of Ethernet and industrial I/O ports, including CAN and serial interfaces, to support automation, telemetry, and machine connectivity. This router fits factories, vehicles, remote cabinets, and IoT edge deployments where robust data links and protocol bridging are required. It runs RutOS with routing, firewall, and remote management features suited for industrial networks.

Key Features

• 4G LTE Cat 4 cellular WAN
• Dual SIM auto-failover support
• Multi-interface I/O (Ethernet, CAN, serial)
• Industrial form factor, DIN-rail mountable

Technical Specifications

SpecificationDetails
Brand Teltonika
Part Number TRB142107000
Product Type 4G LTE Industrial Router
Cellular Technology 4G LTE Cat 4 with 3G/2G fallback
Peak Throughput Up to ~150 Mbps DL / ~50 Mbps UL
SIM Slots 2× Mini SIM (2FF) with auto-failover
Ethernet Ports 1× 10/100 Mbps WAN, 2× 10/100 Mbps LAN
CAN 1× CAN 2.0 interface
Serial 1× RS232, 1× RS485
Digital I/O Multiple digital inputs/outputs
USB 1× USB-A host
GNSS GPS, GLONASS, BeiDou, Galileo, QZSS
Wi-Fi Not included
Power Input 9–30 V DC industrial
Dimensions 105 × 22 × 75 mm (4.13 × 0.87 × 2.95 in)
Weight ~150 g (0.33 lbs)
Operating Temp. −40 °C to 75 °C
Mounting DIN-rail
