Detailed Specifications
Eaton SRCTMTCVR600 Roof Panel Kit for Aisle Containment 600mm
Overview :
The Eaton SRCTMTCVR600 is a roof panel kit designed for hot aisle / cold aisle containment systems in data center environments. It is deployed by data center engineers and facility planners to improve thermal efficiency by physically separating hot and cold airflow paths across rows of rack enclosures.
This kit is engineered for standard 600 mm wide racks and installs above the aisle containment structure to create a semi-sealed thermal barrier. It includes a clear acrylic roof panel and magnetic filler panels with sealing gaskets, enabling light transmission while minimizing air leakage between contained and ambient environments.
In deployment, the SRCTMTCVR600 is used in data centers, white space environments, and high-density server rooms implementing hot aisle or cold aisle containment strategies. It integrates with modular containment systems, including telescopic beam kits and frame assemblies, to form a continuous overhead barrier across rack rows.
From an integration standpoint, the panel kit is part of a larger modular containment ecosystem and is compatible with 600 mm rack enclosures. It is installed between telescopic beams to fill gaps and maintain consistent airflow control across mixed rack configurations. The magnetic filler panels allow flexibility when aligning with varying rack heights or layouts.
A practical deployment example includes installing SRCTMTCVR600 panels above a hot aisle containing blade servers and high-density compute nodes. By sealing the aisle, the system ensures hot exhaust air is directed back to CRAC/CRAH units without mixing with cold intake air, improving cooling efficiency and reducing energy consumption.
This component should not be used as a standalone solution or outside a complete containment system. It is not suitable for open racks without aisle containment infrastructure or environments where overhead clearance is restricted.
Key Features
- Roof panel for 600 mm rack containment systems
- Clear acrylic panel allows overhead light penetration
- Magnetic filler panels with sealing gaskets included
- Supports hot aisle and cold aisle containment layouts
- Designed for modular containment beam integration
Specifications
| Specification | Details |
|---|
| Brand | Eaton |
| Part Number | SRCTMTCVR600 |
| Product Type | Roof Panel Kit (Aisle Containment) |
| Rack Compatibility | 600 mm standard racks |
| Panel Type | Top / roof panel |
| Material | Clear acrylic panel |
| Color | Black (frame/components) |
| Width | 607.1 mm |
| Height | 1247.1 mm |
| Depth | 24.9 mm |
| Weight | 8.6 kg |
| Package Weight | 10.9 kg |
| Included Components | Roof panel, 2 magnetic filler panels, mounting hardware |
| Installation Type | Beam-mounted (modular system) |
| Compliance | RoHS |
| Country of Origin | China |
