Detailed Specifications
HP 719076-B21 - Primary GPU Riser Kit (2-Slot)
Overview :
The HP 719076-B21 is a dedicated riser kit designed for engineers upgrading or configuring the HPE ProLiant DL380 Gen9 server to support GPU- or accelerator-intensive workloads. It replaces the standard primary riser in slot 1 and provides two PCIe 3.0 expansion slots: a full-length, full-height x16 slot and a half-length, full-height x8 slot. These slots enable deployment of double-width GPUs or other large PCIe cards in dual-processor or single-processor configurations. The kit is suited for data-center, HPC, or edge environments where the server chassis must accommodate high-density GPU cards. In multi-server clusters it integrates with HPE management frameworks and adheres to the cooling and power-supply requirements of the Gen9 platform.
Key Features :
Supports one full-length x16 PCIe 3.0 slot
Provides one half-length x8 PCIe 3.0 slot
Designed for double-width GPU card installation
Fits HPE ProLiant DL380 Gen9 slot 1 riser bay
Replaces standard riser kit to enable GPU-ready configuration
Specifications :
| Specification | Value |
|---|
| Brand | HP |
| Part Number | 719076-B21 |
| Product Type | Riser Kit |
| PCIe Slot 1 | Gen3 x16, full-length, full-height |
| PCIe Slot 2 | Gen3 x8, half-length, full-height |
| Compatible Server | ProLiant DL380 Gen9 |
| Supports Double-Width | Yes (for GPUs or accelerators) |
| Replacement of Standard | Yes, replaces primary riser in slot 1 |
| Required Power Supply | Use with recommended high-wattage PS for GPU configurations |
| Cooling Requirements | Must meet server's high-performance ambient fan kit specs |
| Included Slots | 2 total |
| Form Factor | Riser assembly for server chassis slot |
| Free Slots | Both slots free for cards when installed |
| Installation Position | Primary riser slot (slot 1) of chassis |
| Use Case | GPU-/accelerator-enabled server expansions |
