The Samsung M378A1K43CB2-CRC is an 8GB DDR4 memory module designed for compatible desktop computers. With a rated data transfer rate of 2400 MT/s, it provides a standard memory upgrade option for systems that support DDR4-2400 unbuffered DIMMs.
Key Features
- 8GB Capacity: Provides 8GB of system memory for compatible desktop platforms.
- DDR4-2400 Speed: Supports a rated data transfer rate of 2400 MT/s, corresponding to PC4-19200.
- Single-Rank 1Rx8 Organization: Uses a single-rank configuration with x8 DRAM devices.
- Unbuffered, Non-ECC Design: Intended for desktop systems requiring standard unbuffered memory without error-correcting code.
- 1.2V Operation: Uses a specified operating voltage of 1.2V.
Product Overview
Built using DDR4 SDRAM technology, this Samsung module features a 288-pin UDIMM form factor and a single-rank 1Rx8 organization. Its 8GB capacity and DDR4-2400 data rate make it suitable for compatible desktop computers and other systems that explicitly support this memory specification.
The module has a specified CAS latency of CL17. Actual operating speed depends on the motherboard, processor memory controller, and installed memory configuration.
DC Supplies Product Note
Before ordering, verify that your system supports DDR4-2400, 8GB UDIMM modules, and non-ECC memory. This desktop memory module is not a substitute for registered ECC server RAM.
Technical Specifications
| Brand | Samsung |
|---|
| Part Number / MPN | M378A1K43CB2-CRC |
|---|
| Product Type | Desktop memory module |
|---|
| Capacity | 8GB |
|---|
| Memory Technology | DDR4 SDRAM |
|---|
| Memory Speed | 2400 MT/s |
|---|
| Memory Standard | DDR4-2400 / PC4-19200 |
|---|
| Module Type | UDIMM (Unbuffered DIMM) |
|---|
| Rank Configuration | 1Rx8 (Single Rank) |
|---|
| CAS Latency | CL17 |
|---|
| Error Correction | Non-ECC |
|---|
| Buffering | Unbuffered |
|---|
| Operating Voltage | 1.2V |
|---|
| Form Factor | 288-pin DIMM |
|---|
| DRAM Organization | 1G x8 per device; eight devices |
|---|
| Intended Platform | Compatible desktop computers supporting DDR4 UDIMM memory |
|---|
Frequently Asked Questions
1. What is the capacity of the Samsung M378A1K43CB2-CRC?
This module has a total memory capacity of 8GB.
2. What is its rated memory speed?
It is rated for DDR4-2400, with a data transfer rate of 2400 MT/s and a PC4-19200 classification.
3. Is this ECC server memory?
No. It is non-ECC, unbuffered desktop memory and is not registered ECC server RAM.
4. What is the CAS latency?
The specified CAS latency is CL17.
5. What voltage does this module use?
The specified operating voltage is 1.2V.
6. Will it work in any DDR4 computer?
Not necessarily. The computer must support DDR4 UDIMM memory and the module's capacity and specifications. Check the motherboard or system documentation before purchasing.
