The Samsung M323R2GA3EB0-CWM is a 16GB DDR5 memory module designed for compatible desktop computers and systems that support unbuffered DDR5 UDIMM memory. Operating at 5600 MT/s, it offers modern memory bandwidth for everyday computing, multitasking, and supported workstation applications.
Key Features
- 16GB Capacity: Provides 16GB of system memory for compatible desktop platforms.
- DDR5-5600 Speed: Supports a rated data transfer rate of 5600 MT/s.
- Single-Rank 1Rx8 Design: Uses a single-rank memory organization with x8 DRAM devices.
- Unbuffered UDIMM: Designed for desktop systems that require unbuffered, non-ECC DDR5 memory.
- 1.1V Operation: Uses the standard 1.1V operating voltage specified for this module.
Product Overview
This Samsung memory module uses DDR5 SDRAM technology and a 288-pin DIMM form factor. Its 16GB capacity and 5600 MT/s data rate make it suitable for compatible desktop systems requiring this specific memory type and specification.
Before purchasing, confirm that the motherboard or system supports DDR5 UDIMM memory, the required module capacity, and the rated memory speed. This module is unbuffered and non-ECC, so it should not be treated as a replacement for registered ECC server memory.
DC Supplies Product Note
DC Supplies recommends checking the exact part number and system memory requirements before ordering. Memory compatibility depends on the motherboard or system platform, supported memory type, and configuration.
Technical Specifications
| Brand | Samsung |
|---|
| Part Number / MPN | M323R2GA3EB0-CWM |
|---|
| Product Type | Desktop RAM module |
|---|
| Memory Capacity | 16GB |
|---|
| Memory Technology | DDR5 SDRAM |
|---|
| Data Rate | 5600 MT/s |
|---|
| Memory Standard | DDR5-5600 / PC5-44800 |
|---|
| Module Type | UDIMM (Unbuffered DIMM) |
|---|
| Rank Configuration | 1Rx8 (Single Rank) |
|---|
| Error Correction | Non-ECC |
|---|
| Signal Processing | Unbuffered |
|---|
| Operating Voltage | 1.1V |
|---|
| Form Factor | DIMM |
|---|
| Pin Count | 288-pin |
|---|
| Intended Platform | Compatible desktop systems supporting DDR5 UDIMM memory |
|---|
Frequently Asked Questions
1. What is the capacity of the Samsung M323R2GA3EB0-CWM?
This module has a capacity of 16GB.
2. What memory speed does this module support?
It is rated for DDR5-5600, with a data transfer rate of 5600 MT/s. Actual operating speed depends on system support and configuration.
3. Is this registered server memory?
No. The M323R2GA3EB0-CWM is an unbuffered, non-ECC UDIMM intended for compatible desktop systems, not registered ECC server memory.
4. Is this module compatible with every DDR5 computer?
No. Compatibility depends on the system's supported memory type, capacity, and speed. Check the motherboard or system documentation before purchasing.
5. What is the operating voltage?
The specified operating voltage is 1.1V.
6. What is the exact part number?
The exact Samsung manufacturer part number is M323R2GA3EB0-CWM.
