Eaton SRWF6U36 - 6U Vertical Wall-Mount Rack Cabinet 36″ Deep
Overview
The Eaton SRWF6U36 is a 6-rack-unit (6U) vertical wall-mount enclosure engineered to secure and organize standard 19-inch EIA-310 rack equipment in spaces with limited floor footprint. Network and systems engineers deploy it when switches, patch panels, UPS units, or edge servers must be mounted off the floor in wiring closets, retail IT spaces, digital signage closets, or branch office backrooms. Its vertical orientation maintains a low profile while providing structured equipment mounting and routing access.
This cabinet supports 6U of rack space for primary equipment and includes an additional slide-out 2U patch panel mounting bracket at the top for organized horizontal cabling. It accommodates equipment up to 36 in (914 mm) deep, making it suitable for deeper servers, UPS modules, or battery packs that typical shallow wall racks cannot house.
Mechanically, the SRWF6U36 mounts to wall studs or structural backing and extends less than 12 in (305 mm) from the wall, optimizing clearance in compact corridors or small rooms. The frame, constructed from heavy-gauge steel with a black powder-coat finish, provides a static load capacity of 150 lb (68 kg) when anchored properly.
Integration into existing deployments requires only standard wall-mount anchors (user-provided) sized to support equipment weight; the enclosure ships fully assembled with M6 and 12-24 hardware and keyed locks for the front panel. Ventilation cutouts and top/bottom cable routing ports allow passive airflow and structured cable entry/exit.
In practical deployment, use the SRWF6U36 to consolidate edge infrastructure × for example, a 1U PoE switch, a 2U UPS, and cabling patch panels × vertically on a wall near an IDF closet, freeing floor space and improving access for maintenance technicians.
This cabinet should not be used where seismic bracing or vibration damping is required without engineered supports; also avoid outdoor or unconditioned environments as the enclosure is not weather sealed beyond indoor structural protection.
Key Features
- Vertical wall-mount rack with 6U of EIA-310 space
- Supports up to 36″ equipment depth internally
- Slide-out 2U patch panel bracket included
- Lockable vented front door with cable access ports
- Ships fully assembled with mounting hardware
Specifications
| Specification | Details |
|---|
| Brand | Eaton / Tripp Lite |
| Part Number | SRWF6U36 |
| Product Type | 6U Wall-Mount Rack Enclosure |
| Rack Units | 6U primary |
| Additional Patch Panel Space | 2U slide-out bracket |
| Rack Width | 19 inch (EIA-310 compliant) |
| Max Equipment Depth | 36 in (914 mm) |
| Static Load Capacity | 150 lb (68 kg) |
| Mounting Style | Vertical wall mount |
| Material | Steel with black powder coat |
| Enclosure Extension from Wall | < 12 in (305 mm) |
| Cable Access | Top and bottom ports |
| Door | Lockable, reversible vented panel |
| Included Hardware | M6 screws, M6 cup washers, 12-24 screws, keys |
| Ventilation | Vented panels |
| Standards | EIA-310, RoHS |
| Assembly | Ships fully assembled |
| Warranty | Limited (varies by supplier) |
| Country of Origin | China |
