SUPERMICRO COMPUTER SYS-1018D-FRN8T Rackmount Servers View larger

SUPERMICRO COMPUTER SYS-1018D-FRN8T Rackmount Servers

SYS-1018D-FRN8T

New

SuperServer 1018D-FRN8T - 1U - Intel - Xeon - D-1587 - 1.7GHz - 16-Core - DDR4 - Aspeed AST2400 - Power Supply - Redundant - 400Watt - Gigabit Ethernet - 10G SFP+, RJ45 Gigabit Ethernet...
×




Detailed Specifications

Primary Information
System TypeServer
ModelSuperServer 1018D-FRN8T
Cabinet Form Factor1U
Processor / TypeXeon
Processor / ManufacturerIntel
Processor / Clock Speed1.7 GHz
Max Turbo Frequency2.3 GHz
Processor / NumberD-1587
Multi-Core Technology16-Core
Cache Memory Installed Size24 MB
RAM / TechnologyDDR4
RAM / Total Slots Qty4
Hard Drive / Bays Qty4
Networking TypeEthernet
Data Link ProtocolGigabit Ethernet
Graphics ControllerAspeed AST2400
Power / Device TypePower Supply - Redundant
Power / Redundant CapableYes
Power / Provided (W)400 Watt
Power / Voltage Required100 - 240VAC, 50-60Hz
80 PLUS Certification80 PLUS Platinum
Interfaces & Connections10G SFP+, RJ45 Gigabit Ethernet LAN, RJ45 Dedicated IPMI LAN, USB 3.0, VGA
Expansion Slots Total (Free)1x PCIe 3.0 x8 slots M.2 PCIe 3.0 x4, M Key 2242/2280/22110
Width17.2 Inch
Depth16.9 Inch
Height1.7 Inch
Weight8 lbs.
Enclosure ColorSilver
Min Operating Temperature0 Celsius
Max Operating Temperature40 Celsius
Humidity Range Operating8% to 90% (non-condensing)

Special Feature
RoHSY
COOInquire
TAA complianceInquire

Processor
Processor / TypeXeon
Processor / ManufacturerIntel
Processor / Clock Speed1.7 GHz
Max Turbo Frequency2.3 GHz
Processor / NumberD-1587
Multi-Core Technology16-Core
Cache Memory Installed Size24 MB

RAM
RAM / TechnologyDDR4
RAM / Total Slots Qty4

Storage
Hard Drive / Bays Qty4

Networking
Networking TypeEthernet
Data Link ProtocolGigabit Ethernet

Video
Graphics ControllerAspeed AST2400

Power
Power / Device TypePower Supply - Redundant
Power / Redundant CapableYes
Power / Provided (W)400 Watt
Power / Voltage Required100 - 240VAC, 50-60Hz
80 PLUS Certification80 PLUS Platinum

Expansion
Interfaces & Connections10G SFP+, RJ45 Gigabit Ethernet LAN, RJ45 Dedicated IPMI LAN, USB 3.0, VGA
Expansion Slots Total (Free)1x PCIe 3.0 x8 slots M.2 PCIe 3.0 x4, M Key 2242/2280/22110

Dimensions&Miscellaneous
Width17.2 Inch
Depth16.9 Inch
Height1.7 Inch

UNSPSC Code
UNSPSC Code43211502
