APC AR8128BLK - Sliding Rackmount Shelf
Overview
The APC AR8128BLK is a 1U adjustable sliding shelf built for mounting tower equipment, display units, or non-rackable devices inside 19" server racks. It supports mounting depths from 28 in to 40 in, allowing flexibility for different rack installations. With a load capacity of 200 lbs (≈ 91 kg), it gives technicians safe, extendable access to devices during servicing without removing them from the rack. Its durable construction and sliding mechanism simplify equipment maintenance in dense server environments.
Key Features
Adjustable slide depth from 28 in to 40 in for flexible rack setups
200 lb (≈ 91 kg) static load capacity
Occupies only 1U of rack space
Includes mounting hardware and retaining clips
Compatible with standard 19" rack rails
Specifications
| Specification | Detail |
|---|
| Brand | APC (Schneider Electric) |
| Part Number | AR8128BLK |
| Product Type | Sliding Rack Shelf |
| Rack Height | 1U |
| Load Capacity | 200 lbs (≈ 91 kg) |
| Minimum Mounting Depth | 28 in (≈ 711 mm) |
| Maximum Mounting Depth | 40 in (≈ 1016 mm) |
| Width | 17.5 in (≈ 445 mm) |
| Height (shelf thickness) | ~1.7 in |
| Weight | ~35 lb (≈ 15.9 kg) |
| Material | Steel / rugged construction |
| Mounting Kit | Included (rails, hardware, retaining clips) |
| Finish | Black powder coat |
| Slide Mechanism | Telescopic slide rails |
