Detailed Specifications
APC AP6003A Basic Rack PDU
Overview
The APC AP6003A is a compact basic power distribution unit that provides AC power to a small number of rack-mounted devices. It accepts a universal 100-240 V AC input and distributes power through three IEC 60320 C13 outlets, suitable for low-density server, switch, or appliance applications. The vertical Zero U design mounts in the rear channel of standard racks without consuming usable equipment space. It is typically used in wiring closets, small server racks, and constrained edge environments where a few outlets are needed without advanced metering or outlet control.
Key Features
Three IEC 60320 C13 outlets
Universal 100-240 V AC input
IEC 60320 C20 inlet connection
Zero U vertical rack mount
Technical Specifications
| Specification | Details |
|---|
| Brand | APC |
| Part Number | AP6003A |
| Product Type | Basic Rack Power Distribution Unit |
| Input Voltage | 100-240 V AC |
| Input Frequency | 50/60 Hz |
| Maximum Input Current | 10 A |
| Input Connector | IEC 60320 C20 |
| Output Connections | 3 × IEC 60320 C13 |
| Maximum Load Capacity | 1800 VA |
| Mounting Type | Vertical Zero U rack |
| Cord Length | 1.2 m |
| Dimensions (H × W × D) | 310 × 44 × 44 mm |
| Net Weight | 0.6 kg |
| Operating Temperature | 0 - 50 °C |
