APC AP6015A – 8-Outlet Basic Rack PDU View larger

APC AP6015A 8 Outlet Basic Rack PDU

New

ZeroU rack PDU 6×C13
×




  • New

Detailed Specifications

APC AP6015A Basic Rack PDU

Overview

The APC AP6015A is a basic power distribution unit designed to supply AC power to rack‑mounted servers, switches, and peripherals from a single branch feed. It accepts a universal 100–240 V AC input and distributes power via six IEC 60320 C13 outlets. The compact Zero U vertical form factor installs in the rear channel of standard IT racks without occupying usable equipment space. It is typically deployed in data centers, network closets, and edge racks where simple and reliable outlet distribution is required without advanced metering or remote management.

Key Features

  • Six IEC 60320 C13 outlets

  • Universal 100–240 V AC input

  • IEC 60320 C20 inlet connection

  • Zero U vertical rack mount

Technical Specifications

SpecificationDetails
Brand APC
Part Number AP6015A
Product Type Basic Rack Power Distribution Unit
Input Voltage 100–240 V AC
Input Frequency 50/60 Hz
Maximum Input Current 15 A
Input Connector IEC 60320 C20
Output Connections 6 × IEC 60320 C13
Maximum Load Capacity 1800 VA
Mounting Type Vertical Zero U rack
Cord Length 1.8 m
Dimensions (H × W × D) 419 × 44 × 44 mm
Net Weight 0.8 kg
Operating Temperature 0 – 50 °C
