Detailed Specifications
APC AP7822B Basic Rack PDU
Overview
The APC AP7822B is a basic horizontal rack power distribution unit used to supply AC power to multiple rack-mounted devices in standard 19″ cabinets. It accepts a single-phase 120 V input up to 30 A and distributes power through sixteen NEMA 5-20R outlets. The 2U form factor installs in the rack's power bay and is appropriate for data center, wiring closet, or branch office environments where simple, reliable outlet distribution is required without metering or remote management. The unit includes an integrated heavy-duty cord and standard protections for basic load powering.
Key Features
16 NEMA 5-20R output outlets
120 V AC up to 30 A input
Horizontal 2U rack mount
Heavy-duty attached power cord
Technical Specifications
| Specification | Details |
|---|
| Brand | APC |
| Part Number | AP7822B |
| Product Type | Basic Rack Power Distribution Unit |
| Input Voltage | 100-120 V AC |
| Input Frequency | 50/60 Hz |
| Maximum Input Current | 30 A |
| Input Connection | NEMA L5-30P |
| Output Connections | 16 × NEMA 5-20R |
| Maximum Load Capacity | 2880 VA |
| Mounting Type | Horizontal 2U rack mount |
| Cord Length | 3.65 m (≈ 12 ft) |
| Dimensions (H × W × D) | 88 × 444 × 110 mm |
| Net Weight | 3.6 kg |
| Operating Temperature | 0 - 40 °C |
