APC AP7902B 1U Switched Managed Rack PDU
Overview
The APC AP7902B is a managed, switched power distribution unit designed for tight rack deployments where remote control and sequencing of individual outlets are required. IT operations and infrastructure teams deploy this PDU in server cabinets, network closets, and edge racks to remotely power cycle hung devices, enforce startup sequences, and manage power distribution without physical access to equipment. It provides controlled AC distribution while enabling integrated monitoring of load values and outlet status.
This PDU accepts a 100-120 V AC input and distributes power through switched NEMA outlets sized for IT equipment. Individual outlet control allows administrators to isolate faults or reboot equipment remotely via secure network interfaces. Local metering displays aggregate current draw, helping to prevent overload conditions and enabling informed capacity planning in the rack.
The AP7902B occupies 1U of horizontal rack space, making it suitable for deployment in standard 19-inch cabinets where space efficiency is important. The compact form factor supports deployment alongside servers, network switches, firewalls, storage arrays, and appliances without consuming additional vertical rack units that could be used by critical hardware.
Management interfaces include Web, SNMP, and CLI access for remote control, alerting, and configuration. These capabilities integrate with centralized monitoring systems that support SNMP traps or remote scripting to automate responses to power events. Local displays provide at-a-glance feedback on current load, aiding technicians during rack troubleshooting or installation tasks.
This PDU does not include battery backup or uninterruptible power capability; it is not designed to ride through utility outages. For deployments requiring power continuity during outages, the AP7902B should be paired with an uninterruptible power supply upstream in the power chain.
Key Features
• Switched rack PDU with individual outlet control
• 100-120 V AC input distribution
• Remote management via Web, SNMP, CLI interfaces
• Local aggregate current metering display
• Horizontal 1U rackmount form factor
Technical Specifications
| Specification | Details |
|---|
| Brand | APC |
| Part Number | AP7902B |
| Product Type | Switched Rack Power Distribution Unit |
| PDU Type | Managed, switched outlets |
| Input Voltage | 100-120 V AC |
| Nominal Output Voltage | 120 V AC |
| Maximum Input Current | 15 A |
| Load Capacity | ~1440 VA |
| Input Connector | NEMA 5-15P |
| Output Receptacles | 8 × Switched NEMA outlets |
| Metering | Aggregate current display |
| Management | Web, SNMP, CLI |
| Mounting | Horizontal 1U rackmount |
| Dimensions (H × W × D) | 1.73 × 17.5 × 4.25 in |
| Weight | ~5 lb |
| Operating Temp | 0-45 °C |
| Operating Humidity | 5-95 % non-condensing |
