APC AP8862 Metered ZeroU Rack PDU 208V 3-Phase
Overview
The APC AP8862 is a metered rack power distribution unit designed for centralized power distribution and load measurement in high-density rack environments. It is deployed by data center engineers and IT infrastructure teams to distribute three-phase power to multiple rack devices while monitoring current, voltage, and energy use at the distribution level. The unit supports active metering and alarm thresholds to warn when approaching circuit limits, helping prevent overloads in critical IT infrastructure.
This PDU accepts a 208 V three-phase input at up to 20 A and delivers up to 5.76 kVA of load capacity distributed across thirty-six NEMA 5-20R outlets. The rack PDU includes a local LCD display for real-time current and power monitoring, and remote access via standard network protocols enables centralized monitoring and alerting.
The vertical zero-U form factor is designed to mount alongside standard 19-inch racks without consuming usable equipment rack units, preserving space for active systems. Its lightweight profile facilitates installation on rack side rails or vertical mounting points in network closets, enterprise data halls, and colocation environments.
Management interfaces support secure web access, SNMP, and Telnet for remote power utilization monitoring. Integration with broader infrastructure management suites enables alarm thresholds, power trend logging, and coordinated capacity planning across distributed rack deployments.
A practical example deployment includes high-density server or network racks where dozens of outlet connections are required from a single three-phase feed. The AP8862 can power blade chassis, storage arrays, and network switches while providing visibility into real power demand. Workloads feeding off three-phase utility services benefit from the metered design to balance loads across phases and avoid nuisance circuit trips.
This unit is not an uninterruptible power source; it does not provide battery backup or ride-through capability. For installations requiring power continuity during outages, dedicated UPS systems or UPS-PDU integrated designs should be used instead.
Key Features
• Zero-U vertical metered rack PDU, three-phase input
• 5.76 kVA load capacity at 208 V 3-phase
• 36 NEMA 5-20R outlets for extensive device power distribution
• Local LCD plus Web, SNMP, Telnet monitoring interfaces
• Alarm threshold warnings for overload prevention
Technical Specifications
| Specification | Details |
|---|
| Brand | APC |
| Part Number | AP8862 |
| Product Type | Metered Rack PDU |
| Input Voltage | 208 V AC 3-phase |
| Nominal Output Voltage | 120 V AC |
| Input Connector | NEMA L21-20P |
| Maximum Input Current | 20 A |
| Derated Input Current (North America) | 16 A |
| Load Capacity | 5760 VA |
| Output Receptacles | 36 × NEMA 5-20R |
| Metering | Real-time amps, volts, kW, kWh |
| Management Interfaces | Web, SNMP, Telnet |
| Mounting | Zero-U vertical rack |
| Dimensions (H × W × D) | 70.5 × 2.17 × 1.73 in |
| Weight | 13.32 lb |
| Operating Temp | -5 °C to 60 °C |
| Operating Humidity | 5 - 95 % non-condensing |
