Detailed Specifications
APC AP7553 Basic Rack PDU
Overview
The APC AP7553 is a basic rack power distribution unit that delivers single-phase AC power from a high-current branch feed to multiple rack-mounted devices. It accepts a 32 A, 230 V input and distributes power through a mix of twenty IEC-60320 C13 and four IEC-60320 C19 receptacles for servers, storage, and networking gear. The Zero U vertical form factor mounts in the rear channel of standard 19″ racks, preserving usable rack space for active equipment. It is used in data centers, telecom closets, and enterprise racks needing unmanaged, high-density outlet distribution.
Key Features
(20) IEC 60320 C13 output receptacles
(4) IEC 60320 C19 output receptacles
Supports 32 A single-phase 230 V input
Vertical Zero U rack-mount design
Technical Specifications
| Specification | Details |
|---|
| Brand | APC |
| Part Number | AP7553 |
| Product Type | Basic Rack Power Distribution Unit |
| Input Voltage | 230 V AC |
| Maximum Input Current | 32 A |
| Input Connection | IEC 60309 32 A 2P+E |
| Output Connections | 20 × IEC 60320 C13; 4 × IEC 60320 C19 |
| Maximum Load Capacity | 7680 VA |
| Input Frequency | 50/60 Hz |
| Mounting Type | Vertical, Zero U |
| Power Cord Length | ~3.05 m |
| Dimensions (H × W × D) | 1619 × 56 × 44 mm |
| Net Weight | 5.57 kg |
| Operating Temperature | 0 °C to 45 °C |
