APC AP7553 Zero Rack Power distribution Unit View larger

APC AP7553 Zero U Rack PDU 32 A 24-Outlet

New

Vertical zero-U rack PDU, 32 A, 24-outlet
×




  • New

Detailed Specifications

APC AP7553 – Zero-U Rack PDU, 32 A, 24-Outlet

Overview

The APC AP7553 is a vertical, zero-U rack power distribution unit designed for engineers who need dense, reliable AC outlet distribution without consuming rack space. It provides 20 IEC C13 + 4 IEC C19 outlets from a 32 A / ~7.36 kVA input, giving you full coverage for mixed rack loads. It’s ideal in data center or co-location racks where you need to power servers, switches, storage, and auxiliary gear in a compact layout. The device mounts tool-free in NetShelter racks and supports resettable breaker protection to recover quickly from branch overloads.

6. Key Features

  • Vertical zero-U mounting frees up front rack units for active gear instead of PDU hardware

  • 20 C13 + 4 C19 outlets provide flexible power for mixed equipment types

  • Resettable circuit breakers enable fast recovery from overloads without replacing fuses

  • Toolless mounting support for NetShelter racks simplifies installation and repositioning

Technical Specifications

SpecificationDetail
Brand APC (by Schneider Electric)
Part Number AP7553
Product Type Basic Rack PDU / Power Distribution Unit
Input Current / Rating 32 A
Input Voltage 200 / 208 / 230 V AC
Output / Outlets 20 × IEC 60320 C13 + 4 × IEC 60320 C19
Load Capacity / VA ~7,360 V
Dimensions (H × W × D) 1619 × 56 × 44 mm
Net Weight 5.57 kg
Warranty 2-year limited warranty (per Provantage spec)
