Detailed Specifications
APC AP7541 Basic 30A 208V Rackmount PDU
Overview
The APC AP7541 is a basic rack-mounted power distribution unit (PDU) designed to distribute a single high-current AC feed to multiple outlets in IT racks. Data center and network infrastructure teams deploy this unit to provide 200/208 V distribution to rack devices such as servers, switches, storage appliances, and telecom gear. It is a non-managed, non-metered PDU intended for environments where simple, reliable AC distribution without monitoring or remote control is sufficient.
This PDU accepts a 30 A, 200/208 V AC input via a NEMA L6-30P twist-lock connector and delivers it to a bank of high-voltage receptacles sized for typical rack equipment loads. The unit does not include metering, switching, or network connectivity, which simplifies deployment and reduces potential points of failure in basic AC distribution roles.
The form factor is a horizontal 2U rackmount configuration for standard 19-inch cabinets. Integrated mounting brackets and a fixed input cord allow the AP7541 to be installed at a convenient point in the rack, making outlet access straightforward for technicians connecting equipment. Its design supports predictable power distribution in IDF racks, branch office cabinets, telecom closets, and secondary data racks.
Because it is a basic PDU, the AP7541 is not suitable where outlet-level switching, usage metering, or remote power management is required. Installations needing those capabilities should consider metered or switched PDU models. This unit is intended to complement UPS systems or other primary power protection devices by distributing a single high-current feed without active electronic features.
Key Features
• Basic 200/208 V rack PDU with 30 A input
• NEMA L6-30P fixed input connector
• Multiple high-voltage PDU receptacles
• Horizontal 2U rackmount build
• Mounting brackets included
Technical Specifications
| Specification | Details |
|---|
| Brand | APC |
| Part Number | AP7541 |
| Product Type | Basic Rackmount PDU |
| Nominal Input Voltage | 200/208 V AC |
| Input Connector | NEMA L6-30P (30 A) |
| Output Receptacles | 8 × NEMA L6-20R |
| Maximum Input Current | 30 A |
| Load Capacity | ~6 kVA |
| Form Factor | Rackmount (Horizontal) |
| Rack Height | 2U |
| Cord Length | ~10 ft |
| Dimensions (H × W × D) | 3.5 × 17.2 × 3.5 in |
| Weight | ~10.5 lb |
| Mounting Hardware | Included |
| Operating Temperature | 32-104 °F |
| Operating Humidity | 0-95 % non-condensing |
