Eaton SRWF10UMOD 5U Low-Profile Wall-Mount Wiring Enclosure
Overview :
The Eaton SRWF10UMOD is a wall-mount structured wiring and rack enclosure designed for environments where floor space is limited and cable infrastructure needs to be organized securely. It is typically deployed by network and infrastructure engineers in back offices, wiring closets, retail IT closets, classroom AV systems, and other distributed IT locations.
This enclosure provides a 5U vertical mounting platform and a low-profile form factor that extends less than 7 in (≈178 mm) from the wall, supporting up to 150 lb (≈68 kg) of combined rack and non-rack equipment. It includes two removable 1U shelves with adjustable brackets to secure non-rack/network devices such as modems, routers, and patch panels.
The SRWF10UMOD fits shallow switch-depth equipment up to ~16.5 in (≈420 mm) deep, making it ideal for compact network switches, small patch panels, VoIP gateways, and power blocks. Its vented design and built-in RJ45 jacks facilitate cable routing and connectivity, while the reversible locking front door helps secure equipment from tampering.
From an integration perspective, this enclosure supports standard 19-inch, EIA/ECA-310 compliant rack mounting and complements structured cabling systems. It ships fully assembled for immediate wall installation and includes adjustable brackets to accommodate mixed device types without dedicated rack ears.
A practical deployment example includes mounting the SRWF10UMOD in a building entrance closet to house a small network switch, VoIP gateway, and patch panels while consolidating modem and router equipment on the removable shelves. Cable management is facilitated by brush-strip panels and integrated RJ45 connectivity, improving serviceability and reducing clutter.
This enclosure is not intended for high-density server racks or deep equipment exceeding its mounting depth. It also lacks full 4-post rack support and is not suited for heavy UPS systems or large storage arrays.
Key Features
- Low-profile 5U structured wiring wall enclosure
- Supports up to 150 lb (68 kg) combined equipment
- Two removable 1U shelves with adjustable brackets
- Vented panels with brush strips for airflow and cable routing
- Reversible locking front door with combination lock
Specifications
| Specification | Details |
|---|
| Brand | Eaton |
| Part Number | SRWF10UMOD |
| Product Type | Wall-Mount Structured Wiring Enclosure |
| Rack Height | 5U |
| Rack Standard | 19-inch (EIA/ECA-310 compliant) |
| Load Capacity (Static) | 150 lb (68 kg) |
| Maximum Equipment Depth | 16.5 in (419 mm) |
| Height | 35.56 in (903 mm) |
| Width | 20 in (508 mm) |
| Depth (Wall-to-Front) | 10.7 in (272 mm) |
| Weight | ~30.9 lb (~14 kg) |
| Material | Steel with black powder coat |
| Shelves Included | 2 removable 1U with adjustable brackets |
| Cable Features | Brush-strip cable plates, built-in RJ45 jacks |
| Door Type | Reversible locking front door |
| Ventilation | Perforated/vented panels |
| Compliance | RoHS, EIA/ECA-310 |
| Package Contents | Enclosure, shelves, brackets, lock instructions |
