Eaton SRW15USG 15U Wall-Mount Rack Enclosure 20.5in Depth
Overview :
The Eaton SRW15USG is a 15U wall-mount rack enclosure designed for secure deployment of network and IT equipment in space-constrained environments. It is typically installed by network engineers and infrastructure teams managing distributed IT setups such as branch offices, retail sites, and telecom closets where floor-standing racks are not practical.
The enclosure supports standard 19-inch rack equipment with a usable mounting depth of up to 20.5 inches and a total load capacity of 200 lb (90.7 kg). It features a hinged wall-mount design that allows the cabinet to swing away from the wall for rear access during installation and maintenance. The front door includes a shatter-resistant clear acrylic window, enabling visual monitoring of equipment status without opening the enclosure.
This model is deployed in IDF closets, classrooms, retail IT environments, and edge network locations where compact, secure, and accessible rack infrastructure is required. Its low-profile depth makes it suitable for shallow equipment such as switches, patch panels, and compact rackmount devices rather than deep servers or large UPS systems.
From an integration perspective, the SRW15USG supports both square-hole and threaded mounting rails, ensuring compatibility with a wide range of rackmount equipment. It includes vented panels on the front, sides, top, and bottom to support passive airflow, with optional fan kits available for enhanced cooling. Cable access ports at the top and bottom allow structured routing within standard 120V network and power environments.
A practical deployment example includes mounting the SRW15USG in a retail back office to house network switches, firewall appliances, and patch panels. The acrylic window allows quick visual inspection of status LEDs without unlocking the cabinet, reducing maintenance time while maintaining physical security.
This enclosure should not be used in high-density server deployments requiring deep rack space or high load capacity. It is also not suitable for environments needing advanced airflow containment, large rack UPS systems, or full data center scalability.
Key Features
- 15U wall-mount cabinet for shallow-depth equipment
- Clear acrylic front door for visual monitoring
- Hinged design enables rear access without removal
- Supports up to 20.5-inch device mounting depth
- Locking steel enclosure with ventilated airflow panels
Specifications
| Specification | Details |
|---|
| Brand | Eaton |
| Part Number | SRW15USG |
| Product Type | Wall-Mount Rack Enclosure |
| Rack Height | 15U |
| Rack Standard | 19-inch (EIA-310-E) |
| Load Capacity (Static) | 200 lb (90.7 kg) |
| Maximum Device Depth | 20.5 in (520 mm) |
| Minimum Device Depth | 3 in (76 mm) |
| Width | 23.62 in (600 mm) |
| Height | 30.33 in (770 mm) |
| Depth | 21.57 in (548 mm) |
| Weight | ~88 lb (40 kg) |
| Mounting Rails | 4 adjustable vertical rails |
| Rail Type | Square-hole / threaded |
| Door Type | Locking, acrylic window, reversible |
| Side Panels | Locking, removable |
| Cooling Support | Passive ventilation, fan optional |
| Mounting Type | Wall-mount, hinged swing frame |
| Compliance | UL, RoHS, EIA-310-E, IP20 |
