Detailed Specifications
Eaton SRCOMBO - SmartRack Combo Door Handles, 3-Digit Lock
Overview
The Eaton SRCOMBO is a mechanical accessory kit providing combination lock handles for securing both front and rear doors of compatible SmartRack series rack enclosures. It is deployed by IT and facilities teams in network closets, server rooms, and branch sites to enforce basic physical access control without requiring electronic lock systems. The combination lock addresses unauthorized opening of rack doors housing critical IT equipment.
This kit consists of two door handle assemblies with integrated three-digit combination locks and includes a bypass key for administrative override. The combination can be changed as needed when access policies evolve or personnel changes occur. It is designed to fit Eaton's SmartRack floor-standing enclosures with standard door handle cutouts.
SRCOMBO is intended for rack security enhancement in structured IT environments where mechanical locks are acceptable × small to mid-size data centers, colocations, wiring closets, and enterprise edge facilities. It functions with existing SmartRack cabinets without modification to the enclosure structure.
The handles are compliant with RoHS and conform to standard rack accessory form factors, ensuring integration with EIA-310 SmartRack cabinets. Hardware for mounting to both front and rear doors is included in the kit.
In practice, SRCOMBO is installed during rack build-out or as a retrofit to secure rack access × particularly where shared physical spaces or non-IT personnel may be present. The bypass key option mitigates lockout risk when combinations are changed.
Not suitable for environments that mandate electronic access control, audit logging, or integration with centralized identity/access systems, since this is a purely mechanical solution.
Key Features
- Two SmartRack door handles with mechanical combo locks
- Three-digit combination with changeable code
- Bypass key included for administrative override
- Compatible with Eaton SmartRack enclosure doors
- RoHS compliant rack accessory handle kit
Specifications
| Specification | Detail |
|---|
| Brand | Eaton |
| Part Number | SRCOMBO |
| Product Type | SmartRack combo lock handle kit |
| Lock Type | Mechanical, 3-digit combination |
| Bypass Key | Included |
| Quantity | 2 handles (front & rear) |
| Compatibility | Eaton SmartRack series, 19″ EIA-310 |
| Mounting Hardware | Included |
| Compliance | RoHS |
| UPC Code | 037332143204 |
| Product Height | 6 in (152 mm) |
| Product Width | 7 in (178 mm) |
| Product Depth | 2 in (51 mm) |
| Weight | ~1 lb (0.45 kg) |
| Color | Black |
| Country of Origin | Taiwan |
