Detailed Specifications
APC ACCS1001 - Rack Air Containment Rear Assembly
The APC ACCS1001 is a rear-assembly air containment panel designed for use with NetShelter SX 42U and InRow 600 mm rack enclosures. It helps manage the exhaust air path by ensuring hot air is separated from the cold-aisle intake, improving cooling performance and predictability. Ideal for data-centre racks where airflow containment is needed to increase cooling capacity and efficiency. Compatible with standard 600 mm wide cabinets in a 42-U height form factor, it supports environments such as telecom rooms, network closets or small data-centre deployments where controlling rack exhaust is critical.
Key Features
Rear containment assembly shapes the exhaust air path for better cooling efficiency.
Modular design fits 42U NetShelter SX and InRow 600 mm racks, enabling a containment strategy.
Black-finish steel construction offers durability in data-centre racks.
Straightforward installation allows retrofit into existing rack systems with minimal disruption.
Technical Specifications
| Specification | Detail |
|---|
| Brand | APC by Schneider Electric |
| Part Number | ACCS1001 |
| Product Type | Rack Air Containment Rear Assembly |
| Compatible Rack Type | NetShelter SX 42U, InRow 600 mm width |
| Colour | Black |
| Width | 600 mm (approx. 23.6 in) |
| Height | 1,911 mm (approx. 75.24 in) |
| Depth | 196 mm (approx. 7.72 in) |
| Net Weight | ~21.5 kg (~47.4 lb) |
| Material | Steel |
