Detailed Specifications
Intel BX80768245K Desktop Processor
Overview :
The Intel BX80768245K is a retail-boxed Core Ultra 5 245K mainstream desktop processor built on the Arrow Lake architecture. Designed to meet the efficiency and computing baselines of commercial workstations, edge deployments, and corporate productivity hosts, this SKU delivers balanced multi-threaded performance while strictly lowering general power consumption. It integrates hardware-driven infrastructure logic to fulfill computing demands without standard administrative overhead.
Featuring a tailored hybrid core layout, the processor coordinates 6 Performance-cores and 8 Efficient-cores to deliver 14 concurrent hardware threads without utilizing hyper-threading logic.It operates at a baseline frequency of 4.20 GHz for the P-cores and achieves a maximum clock limit of 5.20 GHz under standard operational boost conditions.The architecture integrates a specialized Intel AI Boost Neural Processing Unit (NPU) handling up to 13 TOPS of localized artificial intelligence models, supplemented by 24 MB of shared Intel Smart Cache.
This computing asset deploys directly onto the FCLGA1851 socket, requiring an enterprise motherboard utilizing Intel Z890, Q870, or W880 chipsets.Clocked at a base power envelope of 125W, it reaches a maximal turbo power ceiling of 159W under full computational loads.Because the retail SKU does not pack a factory-bundled cooling mechanism, it must be paired with an aftermarket air or liquid cooling apparatus certified to handle 159W workloads continuously.
The integrated Intel Graphics subsystem native to this architecture supports up to four absolute digital display pipes out of the box.Memory integration supports up to 192 GB of high-speed dual-channel unbuffered DDR5 ECC or non-ECC system RAM running at speeds up to 6400 MT/s. This processor cannot be back-ported to older LGA1700 platforms or memory arrays designed around the DDR4 technical standard.
Key Features :
14-core hybrid processing blueprint delivers efficient concurrent multitasking.
Onboard Intel AI Boost NPU offloads 13 TOPS of machine learning data.
Direct PCIe 5.0 and 4.0 storage architecture supports 24 total platform lanes.
Low 159W maximum turbo power ceiling saves energy in dense deployments.
Unlocked core multiplier permits precise hardware frequency scaling adjustment.
Specifications :
| |
| Brand | Intel |
| Part Number | BX80768245K |
| Product Type | Desktop Processor |
| Total Cores | 14 (6 Performance-cores / 8 Efficient-cores) |
| Total Threads | 14 threads |
| Base Clock Frequency | 4.20 GHz (Performance-core) / 3.60 GHz (Efficient-core) |
| Max Turbo Frequency | 5.20 GHz (Intel Turbo Boost Technology) |
| Cache Size | 24 MB Intel Smart Cache (Shared L3) |
| Processor Base Power | 125 W |
| Maximum Turbo Power | 159 W |
| Memory Support | DDR5 up to 6400 MT/s (Dual-Channel) |
| Maximum Memory Size | 192 GB |
| ECC Memory Supported | Yes |
| Supported Sockets | FCLGA1851 |
| PCI Express Revision | 5.0 and 4.0 (Up to 24 Lanes) |
| Integrated Graphics | Intel Graphics (Up to 4 Displays) |
| Neural Processing Unit | Intel AI Boost (13 TOPS Peak) |
| Maximum Operating Temperature | 105 °C |
