Detailed Specifications
Intel BX80768265KF Desktop Processor
Overview :
The Intel BX80768265KF is a high-performance Core Ultra 7 265KF desktop processor engineered on the Arrow Lake-S platform.Designed for mid-to-high tier computing deployments, engineering workstations, and intense AI compute configurations, this boxed retail processor drops the integrated graphics engine to maximize physical thermal headroom and compute stability under load. It provides an optimized deployment solution for procurement teams scaling enterprise computing fleets without adding auxiliary hardware redundancies.
Utilizing a refined hybrid structural layout, the processor coordinates 8 Performance-cores and 12 Efficient-cores to deliver 20 discrete hardware threads without Hyper-Threading overhead.It functions at a solid base clock frequency of 3.90 GHz for the P-cores and escalates up to a maximum 5.50 GHz via Intel Turbo Boost Max Technology 3.0.The architecture is equipped with a dedicated Intel AI Boost Neural Processing Unit (NPU) processing 13 trillion operations per second (TOPS) to manage local deep learning and automated matrix workloads efficiently.
This processor is built exclusively for the FCLGA1851 socket ecosystem, meaning it requires mandatory deployment on motherboards with compatible Intel 800-series chipsets such as the Z890, Q870, or W880.Operating at a 125W base thermal footprint that scales up to a maximum turbo power limit of 250W, the SKU ships without a factory heatsink. It necessitates a high-capacity liquid or dual-tower air cooling loop to prevent thermal throttling inside edge servers or professional editing stations.
System integration requires pairing this CPU with a discrete, dedicated PCIe graphics card since it lacks onboard video execution. It natively supports up to 192 GB of high-speed dual-channel DDR5 memory with native clocking capabilities reaching up to 6400 MT/s. Avoid implementing this hardware inside legacy LGA1700 mainboards, or pairing it with cooling infrastructure incapable of continuous 250W dissipation under full matrix load conditions.
Key Features :
20-core hardware execution layout drives optimized multi-threaded compute tasks.
Specialized Intel AI Boost NPU offloads up to 13 TOPS of local inference.
Integrated PCIe 5.0 and 4.0 controllers supply 24 direct platform expansion lanes.
Unlocked clock multiplier allows deep performance tuning for heavy compute pools.
Direct Thunderbolt 4 and USB4 architectural support yields extreme data throughput.
Specifications :
| |
| Brand | Intel |
| Part Number | BX80768265KF |
| Product Type | Desktop Processor |
| Total Cores | 20 (8 Performance-cores / 12 Efficient-cores) |
| Total Threads | 20 threads |
| Base Clock Frequency | 3.90 GHz (Performance-core) / 3.30 GHz (Efficient-core) |
| Max Turbo Frequency | 5.50 GHz (Intel Turbo Boost Max Technology 3.0) |
| Cache Size | 30 MB Intel Smart Cache (Shared L3) |
| Processor Base Power | 125 W |
| Maximum Turbo Power | 250 W |
| Memory Support | DDR5 up to 6400 MT/s (Dual-Channel) |
| Maximum Memory Size | 192 GB |
| Integrated Graphics | None (Discrete Graphics Card Required) |
| Neural Processing Unit | Intel AI Boost (13 TOPS Peak) |
| Supported Sockets | FCLGA1851 |
| PCI Express Revision | 5.0 and 4.0 (Up to 24 Lanes) |
| Maximum Operating Temperature | 105 °C |
