Detailed Specifications
Intel CM8070104282718 Desktop Processor
Overview :
The Intel CM8070104282718 is an OEM/Tray 10th Generation Intel Core i5-10400 desktop processor. Engineered for high-volume corporate fleets, commercial business workstations, and integrated client computing platforms, this chip handles everyday multitasking loads efficiently. It provides system builders, original equipment manufacturers, and IT hardware procurement teams with a stable, cost-effective engine for standard enterprise infrastructure deployment.
Fabricated on a refined 14nm lithography framework using the Comet Lake-S microarchitecture, this processor operates at a 2.90GHz baseline speed and triggers up to 4.30GHz via Intel Turbo Boost Technology 2.0. Built with 6 physical cores and 12 logical processing paths via Hyper-Threading, the CPU incorporates 12MB of Intel Smart Cache to smooth over data pipeline execution delays. The integrated memory controller establishes a dual-channel interface supporting up to 128GB of non-ECC DDR4 system memory running at speeds up to 2666MHz over a peak delivery bandwidth of 41.6 GB/s.
The component seats securely into standard FCLGA1200 hardware slots on compatible Intel 400 and 500-series motherboard platform controller hubs. It features an integrated Intel UHD Graphics 630 silicon layout operating up to a 1.10GHz dynamic speed, delivering native video paths for up to three independent 4K workstation displays without requiring an added discrete graphics accelerator card. Do not deploy this tray-packaged processor module in advanced server configurations requiring native PCIe 4.0 lane capacity or error-correcting (ECC) memory architectures.
Key Features :
Six physical cores with 12 logical processing paths optimize multitasking.
4.30GHz maximum turbo velocity drives compute capacity under sudden loads.
On-die Intel UHD Graphics 630 natively runs three independent 4K monitors.
Integrated 12MB Smart Cache memory array reduces core processing latency.
65-watt low thermal profile operates efficiently inside compact office towers.
Specifications :
| Specification Field | Technical Data |
| Brand | Intel |
| Part Number | CM8070104282718 |
| Product Type | Desktop Processor |
| Processor Number | i5-10400 |
| Product Collection | 10th Generation Intel Core i5 Processors |
| Microarchitecture | Comet Lake |
| Total Cores | 6 |
| Total Threads | 12 |
| Base Clock Frequency | 2.90 GHz |
| Max Turbo Frequency | 4.30 GHz |
| Cache Architecture | 12 MB Intel Smart Cache |
| Thermal Design Power (TDP) | 65 Watts |
| Interface Socket | FCLGA1200 |
| Integrated Graphics Engine | Intel UHD Graphics 630 |
| Graphics Base / Dynamic Speed | 350 MHz / 1.10 GHz |
| Memory Support | Dual-Channel DDR4-2666 |
| Max Memory Capacity | 128 GB |
