Detailed Specifications
Intel CM8070104290715 Desktop Processor
Overview :
The Intel CM8070104290715 is an OEM/Tray 10th Generation Intel Core i5-10400 desktop processor. Engineered for high-volume enterprise deployment, mainstream business workstations, and corporate fleet configurations, this chip handles multi-application processing loads efficiently. It provides corporate infrastructure groups and system integrators with a balanced, cost-effective computing solution for standard commercial infrastructure.
Built on a stable 14nm lithography framework using the Comet Lake architecture, the processor functions at a 2.90GHz baseline speed and triggers up to 4.30GHz via Intel Turbo Boost Technology 2.0.Operating with 6 physical cores and 12 processing threads, the chip incorporates 12MB of Intel Smart Cache to smooth over data execution delays.The memory controller provides dual-channel compatibility for up to 128GB of DDR4-2666 system RAM across a peak delivery bandwidth of 41.6 GB/s.
This multi-threaded client component seats inside standard FCLGA1200 hardware slots across matching Intel 400 and 500-series platform controller hubs.Unlike its graphics-disabled counterparts, this unit features integrated Intel UHD Graphics 630 silicon running up to a 1.10GHz dynamic frequency, supporting up to three simultaneous independent 4K displays out-of-the-box. Do not deploy this tray-packaged processor module in infrastructures requiring native PCIe 4.0 lane architecture or heavy-duty server-class ECC memory verification.
Key Features :
Six physical cores with 12 computing threads optimize general multitasking.
4.30GHz maximum boost acceleration handles sudden transaction execution spikes.
Integrated Intel UHD Graphics 630 natively runs up to three 4K displays.
On-die 12MB Smart Cache speeds up low-level local instructions loops.
65-watt low-thermal footprint minimizes office workstation system heat.
Specifications :
| Specification Field | Technical Data |
| Brand | Intel |
| Part Number | CM8070104290715 |
| Product Type | Desktop Processor |
| Processor Number | i5-10400 |
| Product Collection | 10th Generation Intel Core i5 Processors |
| Microarchitecture | Comet Lake |
| Total Cores | 6 |
| Total Threads | 12 |
| Base Clock Frequency | 2.90 GHz |
| Max Turbo Frequency | 4.30 GHz |
| Cache Architecture | 12 MB Intel Smart Cache |
| Thermal Design Power (TDP) | 65 Watts |
| Interface Socket | FCLGA1200 |
| Integrated Graphics Engine | Intel UHD Graphics 630 |
| Max Graphics Dynamic Speed | 1.10 GHz |
| Memory Support | Dual-Channel DDR4-2666 |
| Max Memory Capacity | 128 GB |
