The Ubiquiti UACC-Cable-PT-Ext is a Power TransPort Cable Extender Kit designed for UISP Power TransPort cables. It provides a weather-resistant enclosure for extending compatible Power TransPort cable runs while supporting outdoor deployment conditions.
Power TransPort Connectivity
The extender uses a Power TransPort input/output interface and is designed specifically for compatible UISP Power TransPort cables. It provides a protected connection point within a UV-stabilized polycarbonate enclosure.
Outdoor Protection
Ubiquiti specifies an IPX6-rated design with weather and UV resistance. The enclosure is suitable for outdoor installations and is rated for ambient operating temperatures from -40°C to 80°C.
Mounting
The extender can be mounted to a pole or wall. The specified pole-mount diameter range is 35–60 mm, allowing installation on compatible support structures.
Key Features
- Designed for UISP Power TransPort cables
- IPX6-rated weather resistance
- UV-stabilized polycarbonate enclosure
- Pole and wall-mountable design
- Operating temperature range of -40°C to 80°C
Applications
The UACC-Cable-PT-Ext is intended for outdoor UISP installations where a protected extension point is required for compatible Power TransPort cabling. Its mounting options allow the enclosure to be positioned on suitable poles or walls as part of an outdoor power-cabling deployment.
DC Supplies Product Note
When planning installation, the pole-mounting option is specified for diameters from 35 to 60 mm. The enclosure's IPX6 rating and UV-stabilized construction are relevant when the extender is exposed to outdoor weather conditions.
Specifications
| Specification | Details |
|---|
| Brand | Ubiquiti |
| Part Number / MPN | UACC-Cable-PT-Ext |
| Product Type | Power TransPort Cable Extender Kit |
| Product Family | UISP Power TransPort |
| Input/Output Interface | Power TransPort |
| Weather Resistance | IPX6 |
| UV Resistance | Yes |
| Enclosure Material | UV-stabilized polycarbonate |
| Mounting | Pole or wall |
| Pole Mount Diameter | 35–60 mm (1.38–2.36 in) |
| Wind Resistance | Up to 200 km/h (124.27 mph) |
| Ambient Operating Temperature | -40°C to 80°C (-40°F to 176°F) |
| Ambient Operating Humidity | 10–90% non-condensing |
| Dimensions | 140 × 69.4 × 40.5 mm (5.5 × 2.7 × 1.6 in) |
Frequently Asked Questions
What is the UACC-Cable-PT-Ext used for?
It is a cable extender kit designed for UISP Power TransPort cables.
Is the extender suitable for outdoor use?
Yes. Ubiquiti specifies IPX6 weather resistance and UV-resistant construction for outdoor deployment.
How can the extender be mounted?
The enclosure supports pole and wall mounting. The specified pole-mount diameter range is 35–60 mm.
What temperatures can the extender operate in?
The specified ambient operating temperature range is -40°C to 80°C (-40°F to 176°F).
What interface does the extender use?
The specified input/output interface is Power TransPort.
