Detailed Specifications
The Havis LPS-189 is a 96W non-isolated LIND DC power supply designed for compatible Havis DS-ZEB-400 and DS-ZEB-500 Series docking stations. It accepts a 12–32V DC input and provides a 12V DC output at up to 8A for supported docking configurations.
Designed for vehicle-based installations, the LPS-189 includes a 72-inch input cable with a cigarette-lighter adapter plug and a 72-inch output cable with a straight threaded Switchcraft connector. Mounting hardware is included to support installation with a compatible Havis docking station.
Key Features
- 96W rated output: Provides power for compatible Havis docking stations.
- Wide DC input range: Accepts 12–32V DC input for supported vehicle power systems.
- 12V DC output: Supplies up to 8A to compatible docking configurations.
- Threaded Switchcraft connector: Includes a 72-inch output cable with a straight threaded connector.
- Vehicle installation accessories: Includes a 72-inch cigarette-lighter input cable and mounting hardware.
Compatibility
The Havis LPS-189 is designed for use with compatible Havis docking stations in these series:
- Havis DS-ZEB-400 Series
- Havis DS-ZEB-500 Series
Important compatibility note: The LPS-189 connects to a compatible Havis docking station and is not intended to connect directly to the tablet. Confirm the exact docking station model and power requirements before ordering.
Technical Specifications
| Brand | Havis |
|---|
| Manufacturer Part Number | LPS-189 |
|---|
| Power Supply Manufacturer | LIND |
|---|
| Product Type | DC vehicle power supply |
|---|
| Power Rating | 96W |
|---|
| Power Supply Type | Non-isolated |
|---|
| Input Voltage Range | 12–32V DC |
|---|
| Output Voltage | 12V DC |
|---|
| Output Current | 8A |
|---|
| Input Cable | 72 inches, cigarette-lighter adapter |
|---|
| Output Cable | 72 inches |
|---|
| Output Connector | Straight threaded Switchcraft connector |
|---|
| Gross Weight | 1.25 lb |
|---|
| Mounting Hardware | Included |
|---|
| Compatible Docking Stations | Havis DS-ZEB-400 and DS-ZEB-500 Series |
|---|
Frequently Asked Questions
1. What is the Havis LPS-189 used for?
The LPS-189 supplies DC power to compatible Havis DS-ZEB-400 and DS-ZEB-500 Series docking stations.
2. What input voltage does the LPS-189 support?
It accepts an input voltage range of 12–32V DC.
3. What are its output specifications?
The LPS-189 provides 12V DC output at up to 8A, with a rated output power of 96W.
4. Which docking stations are compatible?
It is specified for compatible Havis DS-ZEB-400 and DS-ZEB-500 Series docking stations. Check the exact docking station model before purchasing.
5. What is included in the kit?
The kit includes the 96W LIND power supply, a 72-inch cigarette-lighter input cable, a 72-inch output cable with a straight threaded Switchcraft connector, and mounting hardware.
