Detailed Specifications
The Havis LPS-167 is a 60W AC power supply designed to power compatible Havis touchscreen displays and selected Zebra docking stations. It accepts 100–264V AC input and delivers 12V DC output at up to 5A.
The LPS-167 features an integrated 48-inch output cable with a straight threaded Switchcraft 761K connector. A detachable 72-inch AC input cable with a three-prong US NEMA 5-15P plug is included for compatible stationary installations, workspaces, and bench-testing environments.
Key Features
- 60W power capacity: Provides up to 60 watts for compatible displays and docking stations.
- Wide AC input range: Supports 100–264V AC input.
- 12V DC output: Delivers up to 5A for supported equipment.
- Threaded output connector: Includes an integrated 48-inch output cable with a straight Switchcraft 761K connector.
- US AC power cable: Includes a detachable 72-inch input cable with a NEMA 5-15P plug.
Technical Specifications
| Brand | Havis |
|---|
| Model | LPS-167 |
|---|
| Product Type | External AC power supply |
|---|
| Power Rating | 60W |
|---|
| AC Input Voltage | 100–264V AC |
|---|
| DC Output Voltage | 12V DC |
|---|
| Maximum Output Current | 5A |
|---|
| AC Input Cable | Detachable, 72 inches |
|---|
| AC Input Plug | Three-prong US NEMA 5-15P |
|---|
| Output Cable | Integrated, 48 inches |
|---|
| Output Connector | Straight threaded Switchcraft 761K |
|---|
| Compatible Displays | Havis TSD-101 and TSD-201 touchscreen displays |
|---|
| Compatible Docking Stations | Selected Havis Zebra DS-ZEB-100, DS-ZEB-200, and DS-ZEB-300 Series docking stations, subject to power configuration |
|---|
Compatibility Notes
The LPS-167 is intended for compatible Havis touchscreen displays and selected Zebra docking stations. Havis specifies compatibility with DS-ZEB-100, DS-ZEB-200, and DS-ZEB-300 Series docking stations that use an internal non-isolated power supply or have no internal power supply. Confirm the exact docking station model and power configuration before ordering.
Frequently Asked Questions
1. What is the Havis LPS-167?
The Havis LPS-167 is a 60W AC power supply for compatible Havis touchscreen displays and selected Zebra docking stations.
2. What output voltage does it provide?
It provides 12V DC output at up to 5A.
3. What AC input voltage does it support?
The specified AC input range is 100–264V AC.
4. Which connector does the output cable use?
The integrated 48-inch output cable uses a straight threaded Switchcraft 761K connector.
5. What cables are included?
The power supply includes an integrated 48-inch output cable and a detachable 72-inch AC input cable with a US NEMA 5-15P plug.
6. Is it compatible with every Zebra docking station?
No. Compatibility depends on the specific docking station model and its power configuration. Check the official Havis compatibility information before use.
