Detailed Specifications
The Havis LPS-140 is a 120W non-isolated DC power supply designed for compatible Havis docking stations for Getac rugged computers. It accepts an 11–32V DC input and supplies a 19V DC output through a right-angle barrel connector.
This power supply kit includes a 72-inch input cable with a cigarette-lighter adapter, a 36-inch output cable, and an LPS-208 mounting bracket for panel mounting. It is intended for compatible vehicle-based computing installations where the docking station requires this power supply configuration.
Key Features
- 120W power rating: Provides power for compatible Havis Getac docking stations.
- Wide DC input range: Supports 11–32V DC input.
- 19V DC output: Supplies the specified output voltage for compatible docking station systems.
- Right-angle barrel connector: Provides the output connection for supported docks.
- Vehicle-ready cable and bracket: Includes a 72-inch cigarette-lighter input cable, 36-inch output cable, and LPS-208 panel-mounting bracket.
Compatibility
Havis lists the LPS-140 for compatible docking stations in the following series:
- DS-GTC-220
- DS-GTC-610
- DS-GTC-800
- DS-GTC-900
- DS-GTC-1000
- DS-GTC-1100
- DS-GTC-1200 and DS-GTC-1210
- DS-GTC-1300
- DS-GTC-1400 and DS-GTC-1410
Confirm the exact docking station model and connector type before ordering. The LPS-140 is different from the LPS-140-BW variant, which uses a bare-wire input configuration.
Technical Specifications
| Brand | Havis |
|---|
| Part number | LPS-140 |
|---|
| Product type | Non-isolated DC power supply |
|---|
| Power rating | 120W |
|---|
| Input voltage | 11–32V DC |
|---|
| Output voltage | 19V DC |
|---|
| Output connector | Right-angle barrel connector |
|---|
| Input cable | 72 inches with cigarette-lighter adapter |
|---|
| Output cable | 36 inches |
|---|
| Mounting accessory | LPS-208 panel-mounting bracket included |
|---|
| Compatible docking stations | Havis DS-GTC-220, 610, 800, 900, 1000, 1100, 1200/1210, 1300, and 1400/1410 series |
|---|
Frequently Asked Questions
1. What is the Havis LPS-140 used for?
The LPS-140 supplies DC power to compatible Havis docking stations designed for Getac rugged computers.
2. What input voltage does the LPS-140 support?
It supports an input range of 11–32V DC.
3. What is the output voltage and power rating?
The power supply is rated at 120W and provides a 19V DC output.
4. What cables and mounting accessories are included?
The kit includes a 72-inch input cable with a cigarette-lighter adapter, a 36-inch output cable, and an LPS-208 panel-mounting bracket.
5. Is the LPS-140 the same as the LPS-140-BW?
No. The LPS-140 uses a cigarette-lighter input cable, while the LPS-140-BW version is configured for bare-wire input. Check the required input connection before purchasing.
