Detailed Specifications
APC AP8712S - Locking C19-to-C20 Power Cord Kit 0.6 m
Overview :
The APC AP8712S is a rack power cord kit comprising six locking IEC power jumpers tailored for structured rack power distribution. It is deployed by data center, network, and systems engineers to secure power interconnects between rack PDU outlets and IT equipment with IEC inputs. The locking feature mitigates accidental disconnects in high-availability power paths.
Each cable in the kit uses IEC 60320 C19 to C20 connectors, supporting up to 16 A in North American and international rack power ecosystems and a compact 0.6 m (2 ft) length to fit within dense rack layouts without excess slack. This is critical where horizontal space and clear routing impact airflow and maintenance access.
AP8712S fits networks, server rooms, and data centers where locked cable retention reduces the likelihood of service disruptions during equipment servicing or vibration events. It pairs with standard 19″ rack power infrastructure and PDUs.
The locking interface engages when used with compatible receptacles such as those on APC AP8000 series Rack PDUs or IT devices designed with matching locking IEC jacks, improving connection security without modifying existing power ports.
In practical deployments, this kit is used for short hop power connections from rack PDUs to servers, storage arrays, or switches. Environments that do not leverage IEC 60320 lock-capable devices (e.g., legacy NEMA-only equipment) will not benefit from the locking functionality and should use standard non-locking cords.
Key Features :
• Six IEC C19→C20 locking jumper cables
• 0.6 m cable length for tight rack routing
• Rated up to 16 A at 250 VAC
• Locking interface with APC AP8000 PDU receptacles
• Black jacket suited to data center environments
Specifications :
| Specification | Detail |
|---|
| Brand | APC |
| Part Number | AP8712S |
| Product Type | Locking power cord kit |
| Connector A | IEC 60320 C20 male |
| Connector B | IEC 60320 C19 female |
| Quantity | 6 cables |
| Cable Length | 0.61 m (2 ft) |
| Current Rating | 16 A |
| Voltage Rating | 250 VAC |
| Operating Temp | 0-75 °C |
| Operating Humidity | 20-80 % |
| Weight | 2.47 lb (1.12 kg) |
| Color | Black |
| Approvals | UL, CSA, CCC, PSE, VDE |
| Mounting | Rack PDU/IT equipment lock receptacles |
