Eaton 9PXPPDM1G2 Power Distribution Module 9PX G2 208V to 120V 8 Outlet PDM

The Eaton 9PXPPDM1G2 PowerPass Distribution Module is an essential accessory designed to seamlessly integrate with Eaton's 3kVA to 6kVA 9PX G2 Uninterruptible Power Supply (UPS) systems. Its primary function is to convert 208V high-voltage input from the UPS to 120V low-voltage output, enabling the connection and power delivery to a broad range of standard IT equipment that typically operates at 120V. This module ensures that critical infrastructure, even with mixed voltage requirements, receives stable and reliable power, preventing compatibility issues and safeguarding operations. Beyond its core voltage conversion, the module incorporates a critical maintenance bypass switch. This feature allows IT administrators to perform routine maintenance, battery replacements, or even full UPS unit swaps without having to power down connected loads. All equipment remains energized directly from utility power during these operations, eliminating costly downtime and maintaining business continuity. With an L6-30P input and a versatile array of output receptacles including L6-30R, L14-30R, and six 5-20R outlets, the 9PXPPDM1G2 offers significant flexibility to connect various types of equipment simultaneously. Designed for adaptable deployment, the PowerPass Distribution Module supports both 3U rackmount and tower configurations, integrating effortlessly into diverse data center or server room environments. It comes equipped with 30A resettable circuit breakers, providing crucial overload protection for connected devices and enhancing the overall resilience of the power infrastructure. This comprehensive approach to power distribution and protection helps IT managers ensure the longevity and performance of their valuable IT assets.

• 208V to 120V power conversion for IT loads.
• Integrated bypass switch for zero-downtime service.
• Multi-outlet NEMA L6-30R, L14-30R, 5-20R support.
• Flexible 3U rackmount or tower installation options.
• Built-in 30A circuit breakers for overload defense.
