Detailed Specifications
Eaton P036-E06-ARD-6 Power Extension Cord 6 Pack
Overview
The Eaton P036-E06-ARD-6 (from the Tripp Lite series by Eaton) is a 6-pack of heavy-duty infrastructure power extension cables equipped with an IEC-320-C19 female receptacle and a locking IEC-320-C20 male plug. This physical hardware kit is engineered to handle high-current electrical distribution inside commercial server racks, joining high-output hardware endpoints to Power Distribution Units (PDUs) or enterprise UPS networks.
Constructed using thick 12 AWG wiring, each 6-foot cable is rated for 250V and 20A, mitigating voltage drop and localized heat generation during heavy continuous loads. The integrated P-Lock hardware on the C20 connector establishes a secure, mechanical dual-tab engagement when mated with P-Lock or compatible PDU high-retention outlets (such as Eaton C39 or G4 PDU configurations). This design choice eliminates accidental disconnects caused by structural vibrations or manual tracing errors during maintenance windows. The red PVC jacket simplifies path classification in dual-feed configurations, though it should not be applied to standard 15A paths requiring smaller C13/C14 interfaces.
Key Features
Dual-tab P-Lock locking C20 connector eliminates accidental power line disconnects
Heavy-duty 12 AWG conductors safely maintain continuous 20A current routing
Extended 6-foot length offers flexible routing options across tall server cabinets
High-visibility red jacket provides instant path grouping in A/B power feeds
Convenient 6-pack configuration accelerates large-scale rack cabinet installations
Specifications
| Feature | Detail |
| Brand | Eaton (Tripp Lite Series) |
| Part Number | P036-E06-ARD-6 |
| Product Type | Power Extension Cord (6-Pack) |
| First End Connector | IEC-320-C19 (Female Receptacle) |
| Second End Connector | IEC-320-C20 with P-Lock (Male Plug) |
| Amperage Rating | 20A |
| Voltage Rating | 250V AC |
| Wire Gauge | 12 AWG |
| Number of Conductors | 3 |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Color | Red |
| Operating Temperature | 23°F to 158°F (-5°C to 70°C) |
| Standards | UL Listed, cUL Listed, VDE Compliant |
