APC PPS330 - Portable Power Station 332 Wh 300 W Output
Overview :
APC PPS330 is a self-contained portable power station engineered for on-the-go energy delivery and short-term backup in environments without fixed mains power. It is specified for technical users who require a compact, transportable source of AC and DC power for equipment and devices in field deployments, remote worksites, outdoor events, or during grid outages. The design solves the need for multi-output power without permanent installation or generator infrastructure.
The internal battery uses lithium-ion chemistry with a usable capacity of 332 Wh and is capable of delivering up to 300 W of continuous AC output via two pure sine wave outlets. Additional DC outputs include USB-A, USB-C Power Delivery, and a 12 V car port, enabling simultaneous powering of laptops, communications equipment, mobile devices, and auxiliary loads. Peak combined output capability is verified at approximately 531 W across all outputs.
Form-factor and construction accommodate deployment where mobility and ease of setup are important: the unit weighs about 3.3 kg and includes a built-in handle and an LCD status display for battery and output monitoring. Pure sine wave AC output maintains compatibility with sensitive electronics that require clean waveform power.
Recharging can be accomplished through several input methods × including AC mains, DC sources, USB-C, or optional solar panel interfaces × providing flexibility for field or off-grid power restoration. Full recharge from an AC wall outlet typically takes about 5 hours; solar recharge times vary based on panel specification.
PPS330 is suitable for small equipment support and mobile operations but is not intended for long-duration mains replacement or heavy industrial loads. The unit should not be deployed in wet or hazardous environments without appropriate enclosures and safety precautions.
Key Features :
• 332 Wh lithium-ion battery capacity
• Two 120 V AC pure sine wave outlets
• USB-C Power Delivery up to 60 W
• Three USB-A ports for DC device power
• Integrated LCD for status and level
Specifications :
| Specification | Value |
|---|
| Brand | APC by Schneider Electric |
| Part Number | PPS330 |
| Product Type | Portable Power Station |
| Battery Capacity | 332 Wh |
| Continuous AC Output | 300 W |
| Peak Combined Output | 531 W |
| AC Outlets | 2 × 120 V pure sine wave |
| USB-A Outputs | 3 × 5 V DC, 2.4 A |
| USB-C Output | 1 × PD up to 60 W |
| Car Port | 1 × 12 V DC, 10 A |
| DC Input | DC and USB-C recharge options |
| Recharge Methods | AC wall, solar, USB-C, DC |
| Display | LCD status panel |
| Weight | 3.3 kg |
| Dimensions (W×D×H) | ~162.6 × 221 × 152.4 mm |
| Housing Material | Plastic |
| Waveform | Pure sine wave |
| Wireless Charging | Yes |
