Detailed Specifications
HPE JW700A - Outdoor PoE+ Midspan Injector (30 W, Gigabit)
Overview
The HPE JW700A (also referenced as model PD-9001GO-NC/NA) is a rugged outdoor PoE+ midspan injector designed to power devices such as outdoor access points or IP-cameras where the existing switch does not supply PoE or you prefer to inject power independently. It supports full Gigabit data (10/100/1000 Mbps) and supplies up to 30 W of power under the IEEE 802.3at standard. The unit includes surge protection and is built for outdoor use × meaning it addresses real-world requirements such as harsh weather, long cable runs and remote mounting conditions. It's ideally suited for campus outdoor wireless or surveillance deployments.
Key Features
Supplies 30 W of PoE+ power (IEC/IEEE 802.3at) × enough for many high-power outdoor APs or IP cameras.
Data port: 10/100/1000 Mbps RJ-45 ensures full duplex gigabit link for the powered device.
Built for outdoor use: includes surge protection and supports temperature extremes (-40 °C to +65 °C) for pole or wall mount.
Plug-and-play, no configuration required × sits between non-PoE switch and powered device, enabling retrofit of PoE in existing infrastructure.
Compatible with a broad range of outdoor APs and cameras, especially where the switch lacks native PoE or you prefer separate power injection.
Technical Specifications
| Specification | Detail |
|---|
| Brand | HPE (Aruba Networking) |
| Part Number | JW700A |
| Product Type | Outdoor PoE+ Midspan Injector |
| Key Specification | PoE Standard: IEEE 802.3at |
| Key Specification | Maximum Output Power: 30 W |
| Key Specification | Data Port: 1 × RJ-45 10/100/1000 Mbps |
| Management | No active management interface (plug-and-play) |
| Power Requirements | AC input (region model dependent ― e.g., NA cord) |
| Dimensions & Weight | Approx. 175 mm × 150 mm × 60 mm; environment-rated |
