Overview
The Panamax M5400-PM MAX is a home theater power management system designed to condition AC power, regulate voltage, and protect connected audiovisual equipment against electrical disturbances. It combines power filtration, surge suppression, automatic voltage monitoring, and controlled outlet switching in a single unit for home theater and professional AV installations.
Power Management and Voltage Regulation
The M5400-PM incorporates voltage regulation to maintain a controlled output when incoming AC voltage fluctuates within its specified operating range. Its Automatic Voltage Monitoring (AVM) circuitry monitors incoming line voltage and disconnects connected equipment when a prolonged overvoltage or undervoltage condition is detected. Power is automatically restored when the voltage returns to a safe range.
Its power filtration system uses five isolated outlet banks to reduce electrical noise transfer between connected components. Sequential power control also helps coordinate the startup and shutdown of connected equipment.
Outlet Configuration and Connectivity
The unit provides 11 AC outlets arranged for different power-management requirements: five always-on outlets, four switched outlets, and two switched high-current outlets. A 12-volt trigger interface supports control of switched outlets by compatible source equipment.
Additional protection circuits are provided for supported LAN, telephone, and coaxial connections. A front-access LAN connection and USB-A charging port are also included in the product design.
Key Features
- Voltage regulation with Automatic Voltage Monitoring and automatic power disconnection during unsafe voltage conditions.
- Level 4+ power filtration with five isolated outlet banks to reduce electrical noise transfer between components.
- Eleven AC outlets comprising five always-on, four switched, and two switched high-current outlets.
- Surge suppression rated at 2,125 joules, with a specified peak impulse current of 72,000 A.
- Sequential power control and a 12 V DC trigger interface for compatible audiovisual equipment.
Applications
The M5400-PM is intended for home theater systems, dedicated AV rooms, media installations, and equipment racks containing compatible amplifiers, subwoofers, source devices, displays, and other audiovisual components. Its isolated outlet banks and sequenced switching are useful where multiple components share a managed AC power source.
DC Supplies Product Note
This model is specified for 120 V AC, 60 Hz power, with an input operating range of 100–136 V AC. It is not directly suitable for connection to a 230 V AC mains supply such as standard Pakistani mains. Verify the installation's input voltage and the unit's electrical requirements before purchase or deployment. A suitable voltage-conversion arrangement must not exceed the product's specified operating limits.
Specifications
| Specification | Details |
|---|
| Brand | Panamax |
| Part Number / MPN | M5400-PM |
| Product Type | Home theater power management system / power conditioner |
| Product Series | MAX |
| Power Filtration Level | Level 4+ |
| Input Voltage | 100–136 V AC operating range |
| Nominal Line Voltage | 120 V AC |
| Line Frequency | 60 Hz |
| Output Voltage | 120 V AC ± 6 V |
| Total Current Capacity | 15 A |
| Number of AC Outlets | 11 |
| Always-On Outlets | 5 |
| Switched Outlets | 4 |
| Switched High-Current Outlets | 2 |
| Isolated Outlet Banks | 5 |
| Surge Energy Dissipation | 2,125 joules |
| Peak Impulse Current | 72,000 A |
| Automatic Voltage Monitoring | Yes |
| Voltage Regulation | Yes |
| DC Trigger | 12 V trigger functionality |
| LAN Protection Interface | RJ-45, 10/100 Ethernet |
| Telephone Protection Interface | RJ-11 |
| Coaxial Protection Interface | Female F-type connectors |
| USB Charging Port | USB-A, 5 V DC at 500 mA |
| Color | Black |
| Warranty | 3-year limited product warranty, subject to manufacturer terms |
Frequently Asked Questions
Can the Panamax M5400-PM be connected directly to 230 V mains?
No. Its specified input operating range is 100–136 V AC, and its nominal line voltage is 120 V AC. Direct connection to a 230 V supply is outside its specified input range.
Does this unit regulate voltage as well as suppress surges?
Yes. It combines voltage regulation, automatic voltage monitoring, power filtration, and surge suppression in one power management system.
Can connected equipment be switched on in sequence?
Yes. Its power-sequencing function coordinates the switching of supported outlet groups, and a 12 V trigger interface allows compatible source equipment to control switched outlets.
Does it provide protection for network and audiovisual signal connections?
The design includes protection circuits for supported RJ-45 LAN, RJ-11 telephone, and coaxial connections. Verify the signal type and connector requirements of the installation before connecting equipment.
Are mounting hardware and connection cables included?
Package contents should be confirmed with the seller for the specific item being supplied. Do not assume that rack-mount hardware, LAN cables, telephone cords, or coaxial cables are included without confirmation.
