APC AP7554 Rack PDU Power Distribution Basic Zero U 16A 230V, 20 Outlets View larger

APC AP7554 Rack PDU Power Distribution Basic Zero U 16A 230V, 20 Outlets

New

Zero-U Basic Rack PDU, 16 A / 230 V
×




  • New

Detailed Specifications

APC AP7554 – Basic Zero-U Rack PDU

Overview :

The APC AP7554 is a basic, non-metered Power Distribution Unit (PDU) used by data center and colocation engineers to distribute AC power within racks. It supports up to 16 A at 230 V and offers a high outlet count for dense rack deployments. Its Zero-U vertical mounting design attaches to the rack’s side rails, preserving usable rack U-space for equipment. It is commonly used in branch, campus, and data center racks and integrates cleanly with standard rack infrastructure.

Key Features :

  • 20 × IEC-320-C13 + 4 × IEC-320-C19 outlets

  • Vertical (Zero-U) mounting on rack side rails

  • 10 ft (3.05 m) power cord terminating in IEC-309 16A plug

  • Acceptable voltage range ±10% (from 230 V nominal)

Specifications :

ParameterValue
Brand APC
Part Number AP7554
Product Type Basic Rack PDU (Zero-U)
Input Connector IEC-309 16 A plug
Nominal Input Voltage 230 VAC
Voltage Tolerance ±10 %
Input Frequency Range 47 – 63 Hz
Output Connectors 20 × IEC-320-C13, 4 × IEC-320-C19
Cord Length 10 ft (3.05 m)
Dimensions (H × W × D) 161.92 × 5.56 × 4.39 cm
Weight 5.56 kg
Operating Temperature –5 to 45 °C
Storage Temperature –25 to 65 °C
Operating Humidity 5 – 95 % RH (non-condensing)
Maximum Elevation (Op) 3,000 m
Maximum Elevation (Storage) 15,000 m
