Detailed Specifications
APC AP9559 - 12 Outlet Basic Rack PDU 16 A
Overview
The APC AP9559 is a basic rack-mount power distribution unit (PDU) designed to deliver reliable AC power to multiple rack-mount devices in data centers, server rooms, and network closets. It distributes up to 3.68 kVA (16 A) of power from a single feed to twelve outlets, supporting 208 V and 230 V environments.
Featuring ten IEC C13 and two IEC C19 outlets, the AP9559 enables versatile connectivity for servers, switches, storage, and other IT equipment. Its 1U horizontal form factor fits standard racks and provides convenient access to outlets close to connected loads.
The unit is intended for basic power distribution where advanced metering or switched control is not required. It is not suitable for environments needing outlet-level switching, remote monitoring, or intelligent load management.
Key Features
- 12 outlets (10 × C13, 2 × C19) for flexible device power
- 1U rack-mountable form factor saves space
- Supports 16 A input and 3.68 kVA total load
- IEC C20 plug with 2.5 m (8.2 ft) power cord
- Horizontal or vertical mounting flexibility
Technical Specifications
| Specification | Details |
|---|
| Brand | APC |
| Part Number | AP9559 |
| Product Type | Basic Rack PDU |
| Outlets | 10 × IEC 60320 C13, 2 × IEC 60320 C19 |
| Input Connector | IEC 60320 C20 |
| Rated Current | 16 A |
| Load Capacity | 3.68 kVA |
| Supported Voltages | 120 V, 208 V, 230 V |
| Mounting | 1U horizontal / vertical |
| Cable Length | 2.5 m (8.2 ft) |
| Form Factor | 1U rack mount |
| Operating Temp | 0 °C to 45 °C |
| Operating Humidity | Up to 95 % |
| Certifications | CE, cUL, UL, VDE |
| Warranty | 2 years |
