Detailed Specifications
Eaton PW103BA1U405 1U Basic Rack PDU with 16 C13 Outlets Compatible Tripp Lite
Overview :
The Eaton PW103BA1U405 is a Basic ePDU 1U rack-mount power distribution unit designed to distribute single-phase AC power to IT equipment installed in standard rack environments. Eaton is the manufacturer, while Tripp Lite is the compatible/product brand associated with the model. Eaton identifies the PW103BA1U405 as a basic PDU with a C20 input and 16 C13 outlets.
The PDU accepts 100-240 VAC, 50-60 Hz single-phase input through an IEC 60320 C20 connection and provides 16 IEC 60320 C13 outlets. It is rated for 16A with a maximum power capacity of 3.33 kW.
The PW103BA1U405 uses a 1U horizontal rack-mount form factor and is intended for data centers, server rooms, network racks and other IT equipment installations requiring centralized rack-level power distribution. Eaton specifies a 19-inch product depth, 1.7-inch height and 7-inch width.
Key Features :
- 1U horizontal rack-mount PDU
- 16 IEC 60320 C13 output receptacles
- IEC 60320 C20 input connection
- 100-240 VAC input range
- 50-60 Hz operating frequency
- 16A current rating
- 3.33 kW maximum power capacity
- Single-phase power distribution
- Basic PDU architecture
- No individual outlet control
- Hardwired input connection
- Designed for standard rack installations
- TAA compliant
- UL Recognized and UL Listed
- CE Marked and TUV certified
- 3-year limited warranty
Specifications :
| SpecificationDetails | |
|---|
| Manufacturer | Eaton |
| Compatible Brand | Tripp Lite |
| Part Number | PW103BA1U405 |
| Product Type | Basic rack PDU |
| Series | Eaton Basic ePDU |
| Form Factor | 1U |
| Mounting Orientation | Horizontal |
| Phase | Single-phase |
| Input Voltage | 100-240 VAC |
| Frequency | 50-60 Hz |
| Current Rating | 16A |
| Maximum Power | 3.33 kW |
| Input Connection | IEC 60320 C20 |
| Output Receptacles | 16 × IEC 60320 C13 |
| Outlet Control | No |
| Cord | Hardwired |
| Rack Height | 1U |
| TAA Compliance | Yes |
