Detailed Specifications
Eaton PDUH20HVL6 single phase 208 240V basic rack PDU
Overview
The Eaton PDUH20HVL6 is a single-phase, 208/240V basic rack PDU designed for high-density IT power distribution in data centers, server rooms, and network infrastructure environments.
It is used to distribute power from a UPS or utility feed to multiple IT devices such as servers, storage systems, and network switches in rack-mounted deployments.
The unit provides 14 total outlets (12 × IEC C13 and 2 × IEC C19) and operates from a NEMA L6-20P input with a 15 ft power cord. It supports up to approximately 3.8 kW of load capacity at 208/240V with a 20A circuit rating.
Its 1U horizontal rack form factor allows installation in standard 19-inch racks, and its switchless design prevents accidental shutdowns in production environments where uptime is critical.
This PDU is intended for basic power distribution only and does not include metering, switching, or remote management features.
Key Features
- 3.8 kW 208/240V basic power distribution for IT racks
- 14 total outlets (12 C13 + 2 C19) for mixed equipment loads
- 1U rackmount design supports horizontal installation
- Switchless operation prevents accidental power interruption
- L6-20P input with 15 ft cord for flexible deployment
Specifications
| Parameter | Value |
|---|
| Brand | Eaton (Tripp Lite series) |
| Part Number | PDUH20HVL6 |
| Product Type | Basic Rack PDU |
| Phase | Single-phase |
| Input Voltage | 208/240 VAC |
| Output Voltage | 208/240 VAC |
| Power Capacity | 3.8 kW |
| Input Current | 20 A |
| Input Connection | NEMA L6-20P |
| Output Receptacles | 12 × IEC C13, 2 × IEC C19 |
| Total Outlets | 14 |
| Cord Length | 15 ft (4.57 m) |
| Form Factor | 1U rackmount |
| Mounting Orientation | Horizontal (rack) |
| Circuit Protection | 20A breaker |
| Frequency | 50/60 Hz |
| Housing Material | Metal |
| Operating Temperature | 0°C to 40°C |
| Compliance | UL 62368-1, RoHS, CSA, FCC Class A |
| Certifications | NOM, TAA |
