Eaton PDUV30HV 0U 208-240V 30A 38-Outlet Basic Rack PDU
Overview :
The Eaton PDUV30HV is a basic, no-management power distribution unit (PDU) intended for delivering high-density AC power in rack environments where simple, reliable distribution is required. It is deployed by data center engineers, network technicians, and facilities teams to aggregate a single high-capacity feed into multiple receptacles for servers, switches, and storage gear. The PDU solves the need for vertical distribution of 208-240 V power in racks without metering, switching, or networked controls.
Electrically, this unit accepts a single-phase 208/240 V AC feed via a NEMA L6-30P 30 A input on an attached 10 ft (3 m) cord. Total distribution capacity is up to ~5.8 kW (30 A max, agency derated to ~24 A continuous) across 38 outlets: 32 IEC-320-C13 and 6 IEC-320-C19. Output outlets are arranged in two banks protected by dual 15 A breakers for overload protection.
Mechanically, the PDU features a 0U vertical form factor that mounts along standard EIA-310 vertical rack posts without consuming usable rack U space. The all-metal housing is ~63.75 in tall, enabling dense power receptacle placement in equipment racks, telco closets, and data center cabinets.
Integration is basic × there are no onboard meters, network interfaces, or outlet switching. This PDU is designed to distribute upstream UPS, generator, or utility power to connected IT equipment, with switch-less design preventing accidental shutdown. It does not support DCIM or remote monitoring.
Typical deployments are in server racks, network cabinets, and edge racks where multiple devices require consolidated 208-240 V distribution from a single 30 A breaker. This model is not appropriate for environments requiring local or remote power monitoring, outlet control, or advanced power management; metered or managed PDUs should be selected for those use cases.
Key Features
- 0U vertical rack PDU with 38 total outlets
- NEMA L6-30P 30 A 208-240 V input, 10 ft cord
- 32 IEC-320-C13 + 6 IEC-320-C19 receptacles
- Dual 15 A breakers protecting outlet banks
- Switch-less basic distribution for UPS/generator feed
Technical Specifications
| Specification | Detail |
|---|
| Brand | Eaton |
| Part Number | PDUV30HV |
| Product Type | Basic Vertical Rack PDU |
| Input Voltage | 208-240 V AC single-phase |
| Input Connection | NEMA L6-30P, 10 ft cord |
| Rated Current | 30 A (agency derated to 24 A continuous) |
| Power Capacity | ~5.8 kW |
| Output Receptacles | 32 × IEC-320-C13, 6 × IEC-320-C19 |
| Protection | Dual 15 A branch breakers |
| Form Factor | 0U vertical EIA-310 rack |
| Mounting | Vertical button-mount and brackets included |
| Dimensions (H×W×D) | 63.75″ × 3.5″ × 2.25″ |
| Weight | ~8 lb |
| Frequency | 50/60 Hz |
| Operating Temp | 0-40 °C (32-104 °F) |
| Compliance | UL 62368-1, RoHS, TAA |
| Cord Length | 10 ft (3 m) |
