Detailed Specifications
Eaton PDUMH20NET - Switched 1U Rack-Mount PDU
Overview
The Eaton PDUMH20NET is a 1U rack-mountable switched power distribution unit (PDU) designed for single-phase 120V environments. It provides remote power control and monitoring for IT equipment, making it ideal for data centers, server rooms, and network closets. The unit supports up to 16 NEMA 5-15/20R outlets and includes a 12-foot NEMA L5-20P input cord. Integrated with the WEBCARDLX network interface, it offers secure remote management via web browser, SNMP, telnet, or SSH. The PDUMH20NET is compliant with the Federal Trade Agreements Act (TAA), suitable for GSA Schedule purchases.
Key Features
Remote Outlet Control: Individually switch and reboot outlets remotely.
Integrated WEBCARDLX: Enables secure remote management via LX Platform.
Digital Current Meter: Front-panel display shows real-time current draw.
TAA Compliant: Meets requirements for federal government procurement.
Horizontal 1U Form Factor: Fits standard rack spaces efficiently.
Technical Specifications
| Specification | Details |
|---|
| Brand | Eaton |
| Part Number | PDUMH20NET |
| Product Type | Switched Rack-Mount PDU |
| Input Voltage | 120V AC |
| Input Current | 16A (Agency de-rated from 20A) |
| Frequency | 50/60 Hz |
| Phase | Single-phase |
| Maximum Output Capacity | 1.9 kW |
| Outlets | 16 x NEMA 5-15/20R |
| Input Cord | 12 ft (3.66 m), NEMA L5-20P / 5-20P |
| Form Factor | 1U Horizontal Rack-Mount |
| Mounting Orientation | Horizontal |
| Material | Steel |
| Dimensions (L x W x H) | 17.5" x 1.75" x 15.5" |
| Weight | 12.5 lbs |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Certifications | UL 60950-1, CSA, NOM, RoHS, FCC Class A |
