Detailed Specifications
Eaton PDUMH20-6 - Metered Rack PDU 20A 120V
Overview
The Eaton PDUMH20-6 is a 20-amp single-phase metered power distribution unit designed for rack-mount environments in data centers, network closets, and IT facilities. It provides reliable 120-volt power distribution from a UPS or utility source to multiple devices. The built-in digital current meter helps monitor load levels and prevent circuit overloads. Its 1U rack-mount design with reversible mounting brackets supports horizontal, wall, or under-counter installation, offering flexibility for varied deployment setups.
Key Features
20-amp single-phase 120-volt input for reliable rack power distribution
Twelve NEMA 5-15/20R outlets for mixed IT and network loads
Integrated digital current meter for real-time load monitoring
6-foot power cord with NEMA L5-20P plug and adapter included
Reversible mounting flanges for horizontal or wall installation
Technical Specifications
| Specification | Value |
|---|
| Brand | Eaton |
| Part Number | PDUMH20-6 |
| Product Type | Metered Rack PDU 120V |
| Input Phase | Single Phase |
| Input Voltage | 100V to 127V AC |
| Rated Current | 20A (16A continuous) |
| Output Capacity | 1.92 kW at 120V |
| Output Receptacles | 12 × NEMA 5-15/20R |
| Input Plug Type | NEMA L5-20P with 5-20P adapter |
| Cord Length | 6 feet |
| Dimensions (H × W × D) | 1.75″ × 17.50″ × 3.75″ |
| Weight | 4.6 lb |
| Minimum Rack Depth | 8.8″ |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -22°F to 122°F (-30°C to 50°C) |
| Form Factor | 1U rackmount, reversible orientation |
