Detailed Specifications
Eaton PDUMH15HVAT - 200-240V ATS/Metered PDU
Overview
The Eaton PDUMH15HVAT is a 1U rack-mount power distribution unit (PDU) combining automatic transfer switching (ATS) with local metering. IT engineers and data center infrastructure teams deploy it where redundant single-phase power feeds must supply single-corded IT equipment without interruption. It solves the risk of downtime from primary power loss by switching to a secondary feed within milliseconds.
This unit accepts dual IEC-320 C14 inputs from separate primary and secondary single-phase sources in the 200-240 V voltage ecosystem. It provides 10 IEC-320 C13 outlets capable of supporting a total load up to ~2.4 kW/10 A, with a built-in digital ammeter that displays total output current.
Physically, the PDUMH15HVAT occupies 1U of horizontal rack space in 19-inch EIA-standard racks and includes rack mounting hardware. Its dual input cords (3.6 m/12 ft each) allow flexible connection to disparate power feeds such as UPS systems, backup generators, or separate mains circuits.
Integration with structured rack power ecosystems is straightforward; included plug-lock inserts secure C13 connections against accidental disconnection and the front panel LEDs provide immediate visual status for inputs and outlets. Optional SNMPWEBCARD/WEBCARDLX cards can be installed to enable remote metering and control via SNMP or web interfaces, although these are sold separately.
In a deployment example, the PDUMH15HVAT ensures connected switches and edge servers remain powered during a primary feed failure in branch IDF closets or core data center racks. This PDU is not appropriate where per-outlet switched control or individual outlet metering is required without optional management cards installed, since its core metering capability reports only total current draw.
Key Features
- Dual IEC-320 C14 inputs for redundant single-phase power
- 10 IEC-320 C13 outlets rated 200-240 V, 10 A total
- Triac solid-state ATS switches in 2-5 ms on power loss
- Front LCD ammeter shows total output current
- Plug-lock inserts secure outlet connections
Specifications
| Specification | Detail |
|---|
| Brand | Eaton (Tripp Lite) |
| Part Number | PDUMH15HVAT |
| Product Type | ATS/Metered Power Distribution Unit |
| Input Voltage Range | 200, 208, 220, 230, 240 V |
| Input Phase | Single-phase |
| Maximum Input Amps | 10 A |
| Power Capacity | ~2.4 kW (at 240 V) |
| Input Connections | (2) IEC-320 C14 |
| Output Receptacles | (10) IEC-320 C13 |
| Rack Units | 1U (19″ EIA) |
| Automatic Transfer Switch | Solid-state (TRIAC), 2-5 ms |
| Metering | Front LCD total current ammeter |
| Cord Length | 3.6 m (12 ft) dual cords |
| Mounting | Horizontal rack mount |
| Weight | ~10.32 lb (4.7 kg) |
| Material | Steel chassis |
| Certifications | UL 60950-1, CE, RoHS, TAA compliant |
| Operating Temp | 32-104 °F (0-40 °C) |
| Humidity | 5-95% non-condensing |
