Eaton PDU1215 - 13-Outlet 120 V Basic Rack PDU
Overview :
The Eaton PDU1215 is a 1U horizontal basic power distribution unit (PDU) designed for distributing single-phase 120 VAC power to multiple pieces of rack-mounted equipment. It is deployed by data-center technicians, network engineers, and facilities teams to deliver utility, UPS, or generator power to servers, switches, storage, and network devices in wiring closets, racks, and telecom cabinets. This unit solves the need for reliable multiple outlet distribution without switching or metered electronics.
This model provides thirteen NEMA 5-15R outlets fed from a NEMA 5-15P input plug on a 15 ft (4.57 m) power cord, delivering up to 1.8 kW (15 A) total across outputs. A 15 A internal circuit breaker protects the strip against overloads. The all-metal chassis has a switchless design that prevents accidental shutdowns and supports diverse power sources, including UPS or generator feeds.
The PDU's 1U, 19-inch EIA-310 horizontal form factor is suitable for standard 2-post and 4-post racks, and detachable mounting flanges enable installation in wall-mount or under-counter orientations. With optional brackets, it can be adapted to 0U vertical mounting in compatible enclosures.
Integration into structured power chains provides a simple distribution point between upstream power sources and downstream gear. Its straightforward pass-through design means it does not include surge protection or metering; those functions require dedicated surge PDUs or metered/managed units.
In practice, PDU1215 is recommended for non-critical basic distribution where outlets from a UPS, generator, or building feed need to be expanded within a rack. It should not be used alone for critical power protection or environments requiring remote power monitoring and switching.
Key Features
• 13 × NEMA 5-15R power outlets
• 1.8 kW / 15 A total load capacity
• NEMA 5-15P input with 15 ft (4.57 m) cord
• Switchless design to avoid accidental shutdown
• Reversible mounting flanges for rack/wall installs
Technical Specifications
| Specification | Detail |
|---|
| Brand | Eaton |
| Part Number | PDU1215 |
| Product Type | Basic Rack PDU |
| Input Voltage | 120 VAC |
| Input Current | 15 A |
| Power Capacity | 1.8 kW |
| Input Connector | NEMA 5-15P |
| Power Cord Length | 15 ft (4.57 m) |
| Output Outlets | 13 × NEMA 5-15R (12 rear / 1 front) |
| Overload Protection | Internal 15 A circuit breaker |
| Rack Mount | 1U horizontal; optional 0U vertical |
| Housing | All-metal chassis |
| Mounting | 19″ EIA-310 rack, wall, under-counter |
| Dimensions (H×W×D) | 1.75″ × 17.5″ × 4.5″ |
| Weight | ~5.2 lb (2.36 kg) |
| Operating Temp | 0 °C to 40 °C |
| Compliance | UL Listed, RoHS |
