Detailed Specifications
Eaton TPC4000-D-LTR - Power Distribution Unit / 24 A 3-Phase
Overview :
The Eaton TPC4000-D-LTR is a rack-mount power distribution unit designed for data-centre and IT-rack environments, providing controlled power delivery to connected equipment. It features a 24 A, three-phase input via NEMA L21-30P and distributes power to ten NEMA 5-20R receptacles. This unit installs in a 1 U rack space and is suitable for branch circuits, server racks, or edge compute racks. Its design includes built-in protection and is intended to integrate into rack power management systems.
Key Features :
3-phase input with NEMA L21-30P plug, supports up to 24 A current
Ten switched NEMA 5-20R output receptacles for equipment connection
Standard 1 U (19″) form-factor, 12 in (304.8 mm) depth for rack installation
Built-in circuit breakers and EMI/RFI filter for surge and spike protection
Specifications :
| Specification | Value |
|---|
| Brand | Eaton |
| Part Number | TPC4000-D-LTR |
| Product Type | Rack-mount Power Distribution Unit (PDU) |
| Input Voltage | 120 / 208 V AC three-phase WYE |
| Input Current | 24 A |
| Plug Type (Input) | NEMA L21-30P |
| Output Receptacles | 10 × NEMA 5-20R |
| Maximum Branch Current | 16 A per branch, up to 24 A per phase |
| Mounting Height | 1 U (1.72 in / 43.7 mm) |
| Width | 19.00 in (482.6 mm) |
| Depth | 12.00 in (304.8 mm) |
| Operating Temperature | 0 °C to 45 °C (32 °F to 113 °F) |
