Detailed Specifications
APC APDU10452MO NetShelter Rack PDU Advanced
Overview
The APC APDU10452MO is a 3-phase, metered-outlet rack PDU (power distribution unit) designed for data centers and network racks needing granular power monitoring. It offers outlet-level and aggregate metering to help balance loads and detect anomalies. The unit supports high-density deployments via a slim vertical form factor and color-coded, 4-in-1 IEC outlets. It is suited for NetShelter and standard racks in core, colocation, or enterprise environments. The PDU integrates with network management (via Ethernet, SNMP) and supports cascading, sensor ports, and hot-swap management module replacement.
Key Features
Metered by outlet and aggregate power reading
42 outlets with 4-in-1 IEC design
3-phase 208 V, 60 A input for heavy loads
Live-swap network management module
Alternating-phase outlet layout for load balance
Technical Specifications
| Attribute | Specification |
|---|
| Brand | APC by Schneider Electric |
| Part Number | APDU10452MO |
| Product Type | Rack PDU, Metered-Outlet (Advanced) |
| Input Voltage | 3-phase, 208 V |
| Current Rating | 60 A |
| Load Capacity | 17.3 kW / 17,300 VA |
| Number of Outlets | 42 total |
| Outlet Types | Combination 4-in-1 (C13/C15/C19/C21) |
| Cord Length | 5.9 ft (1.8 m) |
| Mounting | Vertical, 0U rack side |
| Net Weight | 11.1 kg (24.5 lb) |
| Dimensions (H × W × D) | 1780 mm × 56 mm × 75 mm |
| Communication | Gigabit Ethernet, 10/100/1000, SNMP |
| Environmental Range | -5 °C to 60 °C operating; -25 °C to 65 °C storage |
| Warranty | 3 years, repair or replace |
| Certifications | UL 62368-1, CSA C22.2 No. 62368-1, FCC Part 15 |
